Split-type Air-Conditioner
MXZ-3E54VA
MXZ-3E68VA
MXZ-4E72VA
English is original.
Übersetzung des
Originals
Traduction du texte
d'origine
Vertaling van het
origineel
Traducción del
original
Traduzione
dell'originale
Μετάφραση του
αρχικού
Tradução do
original
Oversættelse af
den originale tekst
Översättning från
originalet
Orijinalin çevirisi
Версията на английски
език е оригинал.
Installation Manual
• This manual only describes the installation of outdoor unit.
When installing the indoor unit, refer to the installation manual of indoor unit.
Installationsanleitung
• Diese Installationsanleitung gilt nur für die Installation des Außengerätes.
Zur Installation des Innengeräts siehe die Installationsanleitung für Innengeräte.
Notice d'installation
• Cette notice ne décrit que l'installation de l'appareil extérieur.
Lors de l'installation de l'appareil intérieur, consultez la notice d'installation de cet
appareil.
Installatiehandleiding
• Deze handleiding beschrijft alleen de installatie van de buitenunit.
Raadpleeg de installatiehandleiding van de binnenunit wanneer u deze instal-
leert.
Manual de instalación
• En este manual sólo se describe la instalación de la unidad exterior.
Para instalar la unidad interior, consulte el manual de instalación de dicha uni-
dad.
Manuale per l'installazione
• Questo manuale descrive solo l'installazione dell'unità esterna.
Per l'installazione dell'unità interna, fare riferimento al relativo manuale di instal-
lazione.
Εγχειρίδιο εγκατάστασης
• Στο παρόν εγχειρίδιο περιγράφεται μόνο η εγκατάσταση της μονάδας εξωτερικού χώρου.
Για την εγκατάσταση της μονάδας εσωτερικού χώρου, ανατρέξτε στο εγχειρίδιο
εγκατάστασης της μονάδας εσωτερικού χώρου.
Manual de Instalação
• Este manual descreve apenas a instalação da unidade exterior.
Quando proceder à instalação da unidade interior, consulte o manual de instalação
da unidade interior.
Installationshåndbog
• Denne håndbog beskriver kun, hvordan udendørsenheden installeres.
Vedrørende installation af indendørsenheden henvises til installationshåndbogen
for indendørsenheden.
Installationsanvisning
• Denna installationsanvisning beskriver endast installation av utomhusenheten.
Se den separata installationsanvisningen för inomhusenheten.
Kurulum Kılavuzu
• Bu kılavuzda yalnızca dış ünitenin kurulumu açıklanmaktadır.
İç ünite kurulum işlemini yaparken iç ünite kurulum kılavuzuna bakın.
Ръководство за монтаж
• Това ръководство описва само монтажа на външното тяло.
При монтиране на вътрешното тяло вижте ръководството за монтаж на
вътрешното тяло.
For INSTALLER
Für INSTALLATEUR
Destinée à l'INSTALLATEUR
Voor de INSTALLATEUR
Para el INSTALADOR
Per il TECNICO INSTALLATORE
Για τον ΤΕΧΝΙΚΟ
Para o INSTALADOR
Til INSTALLATØREN
För INSTALLATÖREN
TESİSATÇI İÇİN
За ИНСТАЛАТОРА
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Português
Dansk
Svenska
Türkçe
Български
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MXZ-3E54VA
Summary of Contents for Mitsubishi Electric MXZ-3E54VA
- Page 1 Split-type Air-Conditioner MXZ-3E54VA MXZ-3E68VA MXZ-4E72VA For INSTALLER Installation Manual English is original. English • This manual only describes the installation of outdoor unit. When installing the indoor unit, refer to the installation manual of indoor unit. Für INSTALLATEUR Installationsanleitung Übersetzung des Deutsch • Diese Installationsanleitung gilt nur für die Installation des Außengerätes.
-
Page 2: Before Installation
Rated Fre- Breaker Max. height Power supply connecting per indoor unit / for per indoor unit / adjustment Cooling Heating Voltage quency capacity difference *9 wire multi-system for multi system A *10 MXZ-3E54VA 25 m / 50 m 25 / 50 4-core 230 V 50 Hz 25 A 3-core 2.5 mm 15 m 20 g/m 50 dB (A) 53 dB (A) MXZ-3E68VA 1.0/1.5 mm 25 m / 60 m 25 / 60 MXZ-4E72VA Note: When connecting the MFZ-KJ series indoor unit(s) to this outdoor unit, charge additional refrigerant according to the instructions in the table below. Pipe length ( L ) No. of MFZ-KJ indoor units... -
Page 3: Selecting The Installation Location
*10 If pipe length exceeds 40 m, additional refrigerant (R410A) charge is re- *4 Use a copper pipe or a copper-alloy seamless pipe. quired. (No additional charge is required for pipe length less than 40 m.) *5 Be careful not to crush or bend the pipe during pipe bending. Additional refrigerant = A × (pipe length (m) - 40) 1-3. SELECTING OPTIONAL DIFFERENT-DIAMETER JOINTS If the diameter of connection pipe does not match the port size of outdoor unit, use optional different-diameter joints according to the following table. (Unit: mm (inch)) Optional different-diameter joints Port size of outdoor unit (port size of outdoor unit → diameter of connection pipe) 6.35 (1/4) → 9.52 (3/8) : PAC-493PI MXZ-3E54VA MXZ-3E68VA MXZ-4E72VA Liquid / Gas 9.52 (3/8) → 12.7 (1/2) : MAC-A454JP 9.52 (3/8) → 15.88 (5/8) : PAC-SG76RJ 12.7 (1/2) → 9.52 (3/8) : MAC-A455JP — A UNIT 6.35 (1/4) / 12.7 (1/2) 12.7 (1/2) → 15.88 (5/8) : MAC-A456JP Refer to the installation manual of indoor unit for the diameter of connection... -
Page 4: Installation Diagram
Obstacles in front, behind and on side(s) Service space Provide space for service and maintenance as shown in the figure. • When installing the unit in an area that is enclosed with walls such as a verandah, be sure to have enough space as shown below. In this case, the air conditioning capacity and power consumption Service space might deteriorate. • When there is a lack of airflow or there is a possibility of becoming 100 or more short cycle, install an outlet guide and make sure there is enough space behind of the unit. 500 or more • When installing two or more units, do not install the units in front or behind each other. 100 or more 200 or more 350 or more 100 or more 350 or more 350 or more 500 or more 500 or more (Unit: mm) Height of the obstacle is 1200 or less 1-5. INSTALLATION DIAGRAM ACCESSORIES Check the following parts before installation. After the leak test, apply insulating (1) Drain socket material tightly so that there is... -
Page 5: Outdoor Unit Installation
2. OUTDOOR UNIT INSTALLATION 2-1. CONNECTING WIRES FOR OUTDOOR UNIT 1) Remove the service panel. Terminal block for power supply 2) Loosen terminal screw, and connect indoor/outdoor unit connecting wire (B) from the indoor unit correctly on the terminal block. Be careful not to make mis-wiring. Fix the wire to the terminal block securely so that no part of its core is appeared, and no external force is conveyed to the connecting section of the terminal block. 3) Firmly tighten the terminal screws to prevent them from loosening. After tighten- ing, pull the wires lightly to confirm that they do not move. 4) Perform 2) and 3) for each indoor unit. 5) Connect power supply cord (A). 6) Fix indoor/outdoor unit connecting wire (B) and power supply cord (A) with the cable clamps. 7) Close the service panel securely. Make sure that 3-2. PIPE CONNECTION is completed. • After making connections between both power supply cord (A) and indoor/ Service panel outdoor unit connecting wire (B), be sure to fix both cable and wire with cable clamps. <OUTDOOR UNIT> Indoor/outdoor unit 15 mm connecting wire Terminal block for 35 mm power supply Terminal block Terminal block Lead wire • Be sure to attach each screw to its correspondent terminal when securing the cord and/or the wire to the terminal block. - Page 6 4. PURGING PROCEDURES, LEAK TEST, AND TEST RUN 4-1. PURGING PROCEDURES AND LEAK TEST Compound pressure 1) Remove service port cap of stop valve on the side of the outdoor unit –0.101MPa Stop valve cap gauge (for R410A) *4 to 5 turns gas pipe. (The stop valves are fully closed and covered in caps in (–760 mmHg) (Torque 19.6 to their initial state.) Pressure gauge 29.4 N•m, 200 *Close (for R410A) 2) Connect gauge manifold valve and vacuum pump to service port of to 300 kgf•cm) *Open stop valve on the gas pipe side of the outdoor unit. Gauge manifold 3) Run the vacuum pump. (Vacuumize for more than 15 minutes.) valve (for R410A) 4) Check the vacuum with gauge manifold valve, then close gauge Handle High Handle manifold valve, and stop the vacuum pump. Hexagonal wrench Charge hose 5) Leave as it is for one or two minutes. Make sure the pointer of gauge (for R410A)
-
Page 7: Test Run
4-4. LOCKING THE OPERATION MODE OF THE AIR CONDITIONER (COOL, DRY, HEAT) • Description of the function: With this function, once the operation mode is locked to either COOL/DRY mode or HEAT mode, the air conditioner operates in that mode only. * Changing the setting is required to activate this function. Please explain about this function to your customers and ask them whether they want to use it. [How to lock the operation mode] 1) Be sure to turn off the main power for the air conditioner before making the setting. 2) Set the “3” of SW1 on the outdoor controller board to ON to enable this function. 3) To lock the operation mode in COOL/DRY mode, set the “4” of SW1 on the SW871 outdoor controller board to OFF. To lock the operation in HEAT mode, set the same switch to ON. - Page 8 DECLARAÇÃO DE CONFORMIDADE CE ДЕКЛАРАЦИЯ СООТВЕТСТВИЯ НОРМАМ ЕС MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD AMATA NAKORN INDUSTRIAL ESTATE 700/406 MOO 7, TAMBON DON HUA ROH, AMPHUR MUANG, CHONBURI 20000, THAILAND hereby declares under its sole responsibility that the air conditioners and heat pumps described below for use in residential, commercial and light-industrial environments: erklärt hiermit auf seine alleinige Verantwortung, dass die Klimaanlagen und Wärmepumpen für das häusliche, kommerzielle und leicht-industrielle Umfeld wie unten beschrieben:...
