IronStrike Cascade Installation And Operation Manual

Free-standing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Free-Standing
Save These Instructions
For Future Reference
P/N 900107-00, Rev. NC, 02/2014
Portland
US
Report No. 050-S-23-2
INSTALLATION AND OPERATION MANUAL
Pellet Stove
P900107-00
A French manual is available upon request. Order P/N 900108-00.
Ce manuel d'installation est disponible en francais, simplement en faire la demande. Numéro de la pièce
900108-00.
This appliance must be properly installed and operated in order to prevent the possibil-
ity of a house fire. Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions could result
• Hot! Do not touch! The glass and surfaces of this appliance will be
hot during operation and will retain heat for a while after shutting off
the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance.
• IHP pellet-burning appliances are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
in property damage, bodily injury or even death. Contact your local building
or fire officials to obtain a permit and information on any installation
requirements and inspection requirements in your area.
WARNING
Pellet Stove
Model Cascade
®
