Read and follow these instructions and all
safety blocks carefully.
Have only trained and qualified persons
install, operate, or service this unit.
Call your distributor if you do not understand
the directions.
cover 6/93 – ST-111 216-A
OWNER'S
MANUAL
CV-2 Control Option
Constant Voltage Control
For Big 30, 30A, 40, And 50 Diesels, And Big 40G Models
For SMAW, GMAW, FCAW, And GTAW Welding
100% Duty Cycle At Welding Generator Rated Load
Adapter And Extension Cords May Be Needed
July 1993
Form: OM-880B
Effective With Serial No. JJ490601
Give this manual to the operator.
For help, call your distributor
or: MILLER Electric Mfg. Co., P.O. Box 1079,
Appleton, WI 54912
414-734-9821
PRINTED IN USA
