Summary of Contents for Zodiac OV 3300

Page 1 OV 3300 OV 3400 OV 3500 RV 4310 RV 4460 RV 4400 RV 4550 RV 5400 RV 5470 RV 5500 Notice d’installation et d’utilisation Français Instructions for installation and use English Montage- und Gebrauchsanleitung Deutsch Installatie en gebruikshandleiding Nederlands Manual de instalación y de uso Espanõl...
Page 2 The colours of certain patterns can also be erased during use or when in contact with objects in the pool. The erased patterns, wear or scratching of vinyl surfaces are not the liability of Zodiac® and are not covered by the limited warranty.
Page 3: Table Of Contents
Contents 1. Information before installing and using ..............2 2. Assembling the transport caddy and the control box on the base ......5 3. Description of the control boxes ................6 4. Starting a cleaning cycle ..................7 5. Programming cleaning cycles for when you are away (RV 5400 - RV 5470 - RV 5500) ..8 6. Using the remote control (OV 3500 - RV 4550 - RV 5500) ............9 7. Maintenance......................10 8. Troubleshooting ....................11 9. Registering the product ..................13 10. Product conformity .................... 13 1. Information before installing and using 1.1 Important Check that your appliance has not been damaged during transport (shocks, broken parts, etc.). If you find any problems do not hesitate to contact your reseller before using the cleaner.
Page 4 1.3 Technical specifications Power supply voltage 220-240 VAC, 50 Hz Control box Cleaner power supply 30 VDC Max. absorbed power 150 W 15 m (OV 3300) 18 m (OV 3400 - OV 3500 - RV 4310 - RV 4400 - RV 4460 - RV 5400 - RV 5470) Cable length 21 m (RV 4550 - RV 5500) Cleaner size (L x W x h) 43 x 48 x 27 cm 69 x 43 x 46 cm (OV 3300) Package size (L x W x h) 56 x 56 x 46 cm Cleaner weight 9.5 kg 14 kg (OV 3300)
Page 5 For optimal performance, place the control box in the centre of the pool, following the safety conditions relat- ing to electrical connection (see § 1.6). 1.6 Electrical connection - Use of an electrical extension is prohibited when connecting the control box. - Choose a dry, flat place free of any objects that may damage the underside of the control box. - Place the control box on the caddy at a distance of at least 3.5 metres from the edge of the pool, avoid plac- ing the control box in direct sunlight.
Page 6: Assembling The Transport Caddy And The Control Box On The Base
2. Assembling the transport caddy and the control box on the base 2.1 Transport caddy 4WD: RV 5400 - RV 5470 RV 5500 2WD: RV 4310 - RV 4400 RV 4460 - RV 4550 OV 3400 - OV 3500 2.2 Attaching the control box on the base (OV 3300) H0491600.B EN - 2014/11...
Page 7: Description Of The Control Boxes
3. Description of the control boxes Control box RV 4400 RV 5400 Symbol description OV 3300 OV 3400 - RV 4310 OV 3500 RV 4550 RV 5500 symbols RV 4460 RV 5470 Start / Stop the cleaner Bottom + sides + water line "Control" indicator Indication "Clean filter" Removal from pool mode Surface to be cleaned* Bottom only Bottom + sides + water line Water line only (RV 5500) Pool shape* Flat bottomed rectangular Other shapes, other bottoms Cleaning time adjustment*...
Page 8: Starting A Cleaning Cycle
4. Starting a cleaning cycle 4.1 Starting up the cleaner Under normal conditions, the cleaner is effective enough that no more than 3 cleaning cycles per week should be necessary. • When you connect the control box, the operating time for the selected cycle is displayed (OV 3500 - RV 4550 - RV 5400 - RV 5470 - RV 5500). • You can launch a cleaning cycle by pressing the button on the control box or the remote control (OV 3500 - RV 4550 - RV 5500). (OV 3500 - RV 4550 - RV 5400 - • The screen then displays the time remaining for the cleaning cycle, example : RV 5470 - RV 5500).
Page 9: Programming Cleaning Cycles For When You Are Away (Rv 5400 - Rv 5470 - Rv 5500)
4.5 Stopping the cleaner • Press the button on the control box. • If you want to stop the cleaner when "remove from pool" mode is active, press the button quickly to stop the cleaner and the control box. RV 4550 - RV 5400 - RV 5470 - RV 5500 - OV 3500 - : The control box switches to standby after 10 minutes and the screen is switched off. Just press any key to exit standby mode. Standby mode does not stop the cleaner if it is in a cleaning cycle.
Page 10: Using The Remote Control (Ov 3500 - Rv 4550 - Rv 5500)
• The LED and the current date and time flash. This is a reminder of the current date and time you entered in order to help you to programme. Press to start programming. If the LEDs flash, this means that the time setting is not complete. To continue with the cleaning cycle programming, it is essential to set the time first. To do this follow the instructions in § 4.1. • Select the day to programme using the buttons. • Validate using the button. • Once the day has been memorised, the hour flashes: • Select the hour to programme using the buttons. • Validate using the button.
Page 11: Maintenance
6.3 Taking the cleaner out of the water ( RV 4550 - RV 5500) • Press the button quickly. The message is displayed. • The cleaner moves toward the wall and climbs up to the waterline. 6.4 Switching off the remote control • Press The remote control is switched off but the cleaner continues to operate. 6.5 Synchronise the remote control with the control box (in the event of a change of remote / control box, or both) If equipment is replaced, it is essential to synchronise the remote with the control box. • Place the remote control about 50 cm away from the control box.
Page 12: Troubleshooting
• Roll the brush around its support and slide the tabs into the fixing holes (3). • Pull on the end of each tab (4) until its edge passes through the slit. • Cut the tabs using a pair of scissors so that they are level with the other blades (5) We recommend that you change the brushes and filter support after 2 seasons usage to preserve the integrity of the cleaner and guarantee optimum performance.
Page 13 8.3 Meanings of the LED FLASHES and the error codes PROBLEMS OV 3500 - RV 4550 OV 3300 - OV 3400 - RV 4310 - SOLUTIONS RV 5400 - RV 5470 RV 4400 - RV 4460 RV 5500 • Check that the cleaner is correctly connected to the control box. If necessary, unplug it and recon- nect it following the appropriate procedure. • Check that nothing is stopping the brushes and tracks from turning correctly (sand, cable, etc.).
Page 14: Registering The Product
Total cleaner operating time (in hours) 3 seconds The last cleaner error code (if the cleaner has had at least one error) 3 seconds The cleaner operating time at the error (if the cleaner has had at least one error) 3 seconds Back to menu: cleaner off, screen on 9. Registering the product Register your product on our website: • You will be kept up to date on new Zodiac® products and special offers, • You can help us to constantly improve our product quality. Europe & Rest of the World www.zodiac-poolcare.com America www.zodiacpoolsystems.com Australia – Pacific www.zodiac.com.au 10. Product conformity This appliance has been designed and built according to the following standards: Low voltage directive: 2006/95/EC Electromagnetic compatibility directive: 2004/108/EC EN 55014-1: 2000 +A1:2001 +A2:2002; EN 55014-2: 1997 +A1:2002...
Page 15 Votre revendeur / your retailer Pour plus de renseignements, merci de contacter votre revendeur. For further information, please contact your retailer. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
