1.2 Rear Side
Status
Ethernet
DC
Alarm
12V
I/O
CONNECTOR
DESCRIPTION
DC 12V
Connect the DC 12V adapter for power supply.
Alarm I/O
Connect to an external device. There are five
connectors, and they're RS485-B, RS485-A,
alarm-out, alarm-in, and GND respectively from
left to right.
Ethernet
Connect the device to the network with the
supplied RJ45 cable.
2
CONNECTOR
DESCRIPTION
DC 12V
Connect the DC 12V adapter for power supply.
Alarm I/O
Connect to an external device. There are five
connectors, and they're RS485-B, RS485-A,
alarm-out, alarm-in, and GND respectively from
left to right.
Ethernet
Connect the device to the network with the
supplied RJ45 cable.
2
