Step 3: Loose the screws on the upper and lower PCB boards.
Step 4: Pull the both PCB boards out and take them apart carefully.
Note: In order not to bend the pins, take the two PCB boards parallelly and slightly
apart, as shown below.
Step 3: Loose the screws on the upper and lower PCB boards again.
Step 4: Pull the both PCB boards out and take them apart carefully.
Note: In order not to bend the pins, take the two PCB boards parallelly and slightly
apart, as shown below.
4
4
