Section 3 − Specifications - Miller Electric CBI 801D Owner's Manual

Rated Output
Welding
At 100%
Range
Duty Cycle
800 Amperes
100 to 800
At 36 Volts DC Amps DC
Conforms with NEMA EW1 (ANSI C87.1), "ELECTRIC ARC WELDING POWER SOURCES," Class I (100).
(1194 mm)
Inches Millimeters
A 62-3/8 1584
B 50-1/2 1283
C 46-1/2 1181
D 36 914
E 28-3/16 716
F 13-3/4 349
G 9-3/4 248
H 6-1/8 156
J
29-7/8 759
K
1-1/16
Figure 3-1. Overall Dimensions And Mounting Hole Locations
SECTION 3 − SPECIFICATIONS
Table 3-1. Welding Generator Specifications
Maximum
Open-Circuit
Engine Speed
Voltage
(OCV)
95 Volts DC
80 Volts DC
Nominal
47 in.
32 in.
(813 mm)
27
Maximum Single-Phase
Auxiliary Power
(No Load) While Welding
3 kVA/kW 60 Hz
1860 RPM
26 Amperes At 120 Volts
72 in.
(1829 mm)
21/32 in. (16.7 mm)
Dia. All Holes
K J
Weight
Net Ship
2150 lbs.
2280 lbs.
(975 kg)
(1034 kg)
A
B
C
E D
F
G
H
ST-147 323-B
OM-166 941 Page 7
