RPR 750IS Series
Insert the blade of the Battery Door tool under the edge of the
metal back-plate of the clip and gently lift enough to release it
from its retaining slot. At the same time slide the clip assembly
towards the bottom of the pager as shown and remove.
Using the Battery Door Tool,
release the battery door catch
and with forefinger, pull the door
away from the case in the
direction shown.
Ensure that the battery door lugs are lifted clear of the case
and remove the door.
Remove the battery, by placing your forefinger onto the
battery positive end-cap and lifting upwards, at the same time
pushing slightly backwards against the negative contact
spring.
Battery replacement is the
reverse sequence. Place the
battery negative against the
sleeve-contact and spring
and compress slightly, at the
same time pushing the
battery into the compartment
and engaging the positive
end-cap, against the positive
contact in the pager.
21
Battery door catch
Clip back-
plate retaining
slot
Battery door
locating/locking
lugs
9261-7912 Issue 8
