Turning ON the System

Turn the unit ON using the Power Switch located on the right side of
control panel of the camera housing. The lighting should illuminate
the Viewing Table.
If the Lights do not illuminate and the screen does not
turn on, please check the power cord connections
described in the previous section.
The screen should come on after a normal delay of several seconds.
If the screen does not turn ON after a few seconds, press the Monitor
Power button located in the lower right corner of the Monitor below
the screen. The Monitor settings are set at the recommended settings
so there is not need to adjust the monitor settings.
Place reading material or your hand under the camera to confirm the
video image displays on the monitor.

Selecting Viewing Mode

Located on the Camera Control Panel, the Mode Switch allows a choice
of Full Color viewing along with selected Black & White and Reversed
Black & White combinations for optimal viewing, based on your unique
vision needs.
Section 2: Features & Instructions
POWER Switch
4
