Quick Start Guide

Hardware Installation

1
Make sure the WAH7003 is turned off. Slide open the bottom cover
1
from the back of the WAH7003.
1
Remove the battery, if any. Gently push the SIM card into the SIM
2
card slot with the gold contact points facing down.
1
Insert the battery with the gold contact points on the battery facing
3
the gold contact points in the battery compartment. Replace the
bottom cover.
1
(Optional) Open the memory card slot cover. Insert a micro SD card
4
(up to 32GB in size) with the slanted side matching the card holder
and the metal contact area facing downwards into the slot, and then
push the memory card as far as possible.
Connect the micro USB port to a power adaptor using a micro USB
cable, and then connect the power adaptor to an appropriate power
5
outlet to charge the battery.
After the battery is fully charged, remove the WAH7003 from the
power adaptor.
6
To turn on the WAH7003, press the power button and hold until
"ZyXEL" displays in the OLED screen.
To turn off the WAH7003, press the power button and hold until
"BYE" displays in the OLED screen.
Connect the micro USB port of the WAH7003 to the USB port of your
computer. Check the Windows taskbar or the Macintosh pop-up
7
window to see if the WAH7003 is installed properly.
1/2
WAH7003
3G Portable Router
WPS
Power
