  • Page 1: User Manual

    PHV 132512/ PHV 132514 User Manual...
  • Page 2 WEEE Directive & Product Disposal At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal.
  • Page 3 Notice Please turn the flange 25 degrees to the left (counter clockwise ) to remove the flange from the unit and prepare to install.

  • Page 4: Package Contents

    Package Contents PeepHole Viewer Locking Screw Base Flange PeepHole Lens PeepHole Barrel Tightening Tool 2 AA Batteries FOR BEST RESULTS PLEASE USE THE PEEPHOLE INCLUDED Power button Battery Low Light Battery cover IF THE LOW BATTERY LIGHT IS FLASHING, PLEASE REPLACE THE BATTERIES.

  • Page 5: Before Installation

    Before Installation Prior to mounting the PeepHole Viewer, please make sure you have installed the batteries included.

  • Page 6: Installation

    Installation Insert PeepHole lens in the outside of the door. Insert the PeepHole barrel through Base Flange and insert both into the hole on the inside of the door. Tighten the PeepHole Barrel with your fingers. When the barrel is snug, rotate the Base Flange until the TOP icon is at 12 o’clock (vertical).
  • Page 7 Hold the PeepHole Viewer at a -25 degree counter-clockwise position and insert it onto Base Flange. Rotate the PeepHole Viewer clockwise until horizontal and you feel it lock in place. Use the screwdriver to tighten the Locking Screw. You are now ready to turn the PeepHole Viewer on.
  • Page 8 Thank you for purchasing Brinno’s PeepHole Viewer! If you have any questions or problems setting up your Brinno PeepHole Viewer please contact the sales staff where you purchased our product or email us at Brinno Incorporated directly.
