Connecting the CS60 Headset System
to the PUBLIC III Microphone Loudspeaker Unit
Central Unit
Ref. 40.054.311
RJ 45
8-pole
RJ 45
8-pole
RJ 10
4-pole
Microphone Loudspeaker Unit
- bottom side -
Ref. 40.054.301
RJ 10
4-pole
RJ 45
8-pole
RJ 45
8-pole
Ref. 40.054.327
Patch cable with RJ45 connector(8/8-pole), 3 m
Central unit <—> Microphone loudspeaker unit
Ref. 40.054.376
Patch cable with RJ10 connector (4/4-pole), 3 m
Microphone loudspeaker unit <—> CS60 Base station
Ref. 40.054.378
Patch cable with RJ45/RJ10 connector (8/4-pole), 3 m
Central unit <—> CS60 Base station
