Connecting the CS60 Headset System
to the PUBLIC III Central Unit
Central Unit
Ref. 40.054.311
CS60 Base Station
Ear-loop &
Over-the-hed style
Ref. 40.030.004
2
RJ45
8-pole
patch cable with
RJ45 / RJ10 modular jack
(8-pole / 4-pole)
Ref. 40.054.378
RJ10
Mains Connection
4-pole
CS60 Base Station
- bottom side -
Notes:
7
