ABOUT THIS MANUAL

This document describes the ADC ClearGain 900/1800 MHz tower mounted amplifier system and
provides complete instructions for installing this product on a communications tower.

ADMONISHMENTS

Important safety admonishments are used throughout this manual to warn of possible hazards to
persons or equipment. An admonishment identifies a possible hazard and then explains what
may happen if the hazard is not avoided. The admonishments — in the form of Dangers,
Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of
the triangular alert icon (seen below), and are listed in descending order of severity of injury or
damage and likelihood of occurrence.
Danger: Danger is used to indicate the presence of a hazard that will cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Warning: Warning is used to indicate the presence of a hazard that can cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Caution: Caution is used to indicate the presence of a hazard that will or can cause minor
personal injury or property damage if the hazard is not avoided.

CERTIFICATION

ClearGain 900/1800 MHz has been tested and meets the CE requirements.

STANDARDS

The following listing is a bibliography of applicable regulatory standards:
Safety
EMC
Storage
Transport
Operation

LIST OF ACRONYMS

ANT -- Antenna (Port on MHU)
BTS -- Base Transceiver Station
MHU -- Masthead Unit
PDU -- Power Distribution Unit
RF -- Radio Frequency
TMA -- Tower Mounted Amplifier
EN60950
EN55022B
ETS3019-1-1
ETS3019-1-2
ETS3019-1-4
ADCP-75-154 • Issue 3 • August 2006 • Preface
© 2006, ADC Telecommunications, Inc.
Page v
