2.3.3 Setting the DIP Switch on the PDU
The PDU has a DIP switch to disconnect unused MHU outputs (see
outputs that are used, the DIP switch must be in the "down" position. Unused outputs must be
disconnected by setting the DIP switch to "ON".
(Switches 1, 2, 3, and 6 Set to "Down" to Indicate Use of MHU Ports 1, 2, 3, and 6)
Page 10
© 2006, ADC Telecommunications, Inc.
POWER DISTRIBUTION UNIT
ALARM
RELAY
DC
INPUT
NO COM
(COMMON) (NORMALLY
OPEN) CLOSED)
Figure 10. PDU Alarm Logic
Figure 11. Example of DIP Switch Setting on the PDU
PDU
ALARM
LOGIC
OUTPUTS
NC
16773-A
Figure 11). For the MHU
