- Page 1 Monterings- og betjeningsvejledning Side 2-7 Montage- und Bedienungsanleitung Seite 8-13 Installation and user´s manual Page 14-19 Jydepejs H530 - Fire by Design...
- Page 2 2. Installation Jydepejsen stoves are tested by specialist institutions and approved according to applicable legislative requirements. Before final approval is granted, stoves have to successfully complete a variety of combu- stion tests. The insert tested featured a top outlet. The wood used for the tests was birch, with a moisture content of 15–21%.
- Page 3 Before placing of the vermiculite panels: In case you have chosen a Jydepejsen stove collar (accessory): Place it in the smoke outlet hole - remember the gasket at the bottom. After this, bend the 4 small plates to fix the collar.
- Page 4 Any claims during the warranty period should be addressed to the dealer from whom you purchased the stove. All stoves from Jydepejsen come with their own individual serial number on the boiler plate on the back of the stove. In connection with service procedured of all kinds, please quote the stove model and serial number.
- Page 5 This is completely normal for sheet metal components, and cannot be considered a defect in the stove. All Jydepejsen stoves are intermittent. Initial lighting 1. Place fire-lighters and 2 kg of kindling on the bottom of the combustion chamber.
- Page 6 5. Maintenance Gaskets and vermiculite panels are wearing parts which need to be replaced from time to time – depending on how much you use your stove. In some cases, you may need to replace them every year, while in others, replacement every second or third year will suffice.
- Page 7 Spare parts list Article No. Article description Dimensions H x B x D mm 413003-00 Vermiculite bottom panel 305 x 299 x 25 413004-00 Vermiculite baffle plate 558 x 300 x 28 413002-00 Vermiculite rear panel 637 x 247 x 20 413001-00 Vermiculite side panel 430 x 305 x 20...
