Fuses
This charger is protected by a 10A input and 7.5A output spade fuse. If you need to replace a fuse, your local hobby
retailer should be able to supply one. You can also find replacement fuses at automotive stores. Always replace your
fuse with a new fuse of the same rating.
Safety Precautions
• Do not leave your battery and charger unattended during use.
• Always allow charger to cool between charges.
• Never connect the charger to an automobile 12V battery while the vehicle is running.
• F aceplate can become hot during charging. Keep the charger away from any material that may be affected by heat.
• Carefully observe connector polarities at all times.
• Do not let children charge battery packs without adult supervision.
• I f either charger or battery becomes hot to the touch during the charge process, end the charge process immediately.
Warranty and Repair Policy
This charger is guaranteed against workmanship and manufacturing defects for a period of 5 years from the original date
of purchase. This warranty is limited to the original purchaser and is not transferable. Warranty repair will not cover units
that have been modified, misused or serviced by an unauthorized service center.
To speak to a service technician, call 1-877-504-0233.
If your charger needs to be repaired, ship the charger in its original box (freight prepaid) to:
Horizon Service Center
Attn: Dynamite Service
4105 Fieldstone Rd.
Champaign, IL 61822
Include your complete name and address information inside the carton and clearly write it on the outer label/return
address area. Include a brief summary of the difficulty. Date your correspondence and be sure that your name and address
appear on this enclosure. Also, please include a phone number where you can be reached during the business day.
Warranty Repairs
To receive warranty service, you must include your original sales receipt verifying the proof-of-purchase date. Providing
warranty conditions have been met, your charger will be repaired free of charge.
Non-Warranty Repairs
Should your repair cost exceed 50% of the retail purchase cost, you will be provided with an estimate advising you of
your options. Any return freight for non-warranty repairs will be billed to the consumer. For non-warranty repairs, please
advise us of the credit card you prefer to use. Horizon Service Center accepts Visa and MasterCard. Please include your
card number and expiration date. Horizon Service Center also accepts money orders.
5
Made in Taiwan
© 2006 Horizon Hobby, Inc.
Dynamite
products are distributed exclusively by Horizon Hobby, Inc., Champaign, IL U.S.A.
®
www.horizonhobby.com
7095.1
DC VISION PEAK
ULTRA
Peak Charger
For 1–8 Cell Ni-Cd, Ni-MH and 1–3 Cell Lithium Polymer (Li-Po) Battery Packs
• Vision LCD icon shows charge status
• Multi-function LCD shows charge time, charge current and voltage
• C harges virtually all 1- to 8-cell Ni-MH & Ni-Cd packs and
1- to 3-cell Li-Po packs
• Adjustable charge rates from 0.1A–5A (Ni-MH & Ni-Cd)
• Adjustable charge rates from 0.1A–3A (Li-Po)
• Input and output circuit protection
• Automatic trickle charge
• Limited 5-year warranty
™
