- Page 1 INSTRUCTIONS FOR Models: Supermig185 195/9. 0051 (2) 180900 SUPERMIG...
-
Page 2: Safety Instructions
S U P E R M I G 1 8 5 , S U P E R M I G 1 9 5 / 9 , Thank you for purchasing a Sealey Welder. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you years of trouble free performance. -
Page 3: Introduction And Description
Your welder has a Euro Connection. Line up pins in the torch with the appropriate holes in the machine, push in and tighten knurled knob (fig. 5 A). When welding is finished remove torch and store in a safe place. Note: damage to torches and cables is not covered by warranty. Supermig185, 195/9, 0051 (2) 180900... -
Page 4: Maintenance
IMPORTANT: BEFORE YOU COMMENCE, MAKE SURE THE MACHINE IS SWITCHED OFF AT THE MAINS. IF WELDING A CAR, DISCONNECT THE BATTERY OR FIT AN ELECTRONIC CIRCUIT PROTECTOR. WE STRONGLY RECOMMEND THE USE OF SEALEY “PROSAF/12V OR 24V IN ORDER TO PROTECT SOPHISTICATED ELECTRONICS. ENSURE YOU HAVE READ & UNDERSTOOD THE ELECTRICAL SAFETY INSTRUCTIONS IN CHAPTER 1. -
Page 5: Changing Gears
To keep the contact tip free from spatter, we recommend the use of Sealey anti-spatter spray (MIG/722307) available from your Sealey Dealer. 6. 6. Replacing the Liner Wind the wire back on to the spool and secure it. - Page 6 120/990257 Gear Kit 120/990264 Reel Kit *195/9 exceptions to the above list: Item Part No Description 120/322200 Fixed Wheel 120/322246 Wheel Sealey Group 120/422969 Swivel Support 01284 757500 Bury St. Edmunds, 120/644077 Back Panel 120/644078 Diaphragm Suffolk. 01284 703534 120/648462...
- Page 7 WIRING DIAGRAM FOR SUPERMIG MODELS185, & 195/9. TORCH PART No’s Item Part No Description 722423 Conical Nozzle 722415 Contact Tip D.0.6 722416 Contact Tip D.0.8 722319 Nozzle Spring 722326 Diffuser Insulation 722823 Swan Neck Insulation 722822 Swan Neck Diffuser 722819 Gun Plug Housing 722665 Complete Handle...
