INSTALLATION INSTRUCTIONS
HB0115
MODEL E661
!
INTENDED FOR DOMESTIC COOKING ONLY
!

READ AND SAVE THESE INSTRUCTIONS

INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 & 13.
Broan-NuTone Canada ULC; Mississauga, Ontario
www.broan.ca 1-877-896-1119
REGISTER YOUR PRODUCT ONLINE AT: www.broan.com/register
21236 Rev. 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E661 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Broan E661

Summary of Contents for Broan E661

  • Page 1: Read And Save These Instructions

    INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 & 13. Broan-NuTone Canada ULC; Mississauga, Ontario www.broan.ca 1-877-896-1119 REGISTER YOUR PRODUCT ONLINE AT: www.broan.com/register 21236 Rev. 01...
  • Page 2 WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR TO REDUCE THE RISK OF INJURY TO PERSONS IN THE INJURY TO PERSONS, OBSERVE THE FOLLOWING: EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*: 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address 1.

  • Page 3: Table Of Contents

    IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and service.

  • Page 4: Install Ductwork

    1. INSTALL DUCTWORK Plan where and how the ductwork will be installed. Install proper-sized ductwork, elbows and roof or wall cap. Use 2” metal foil duct tape to seal joints. We recommend to install the hood at a minimum distance of 24” from an electric range and 30” from a gas range. Distances over 30”...

  • Page 5: Prepare Hood

    2. PREPARE INSTALLATION ( CONT'D ORIZONTAL DISCHARGE ERTICAL DISCHARGE CABINET BOTTOM Cut-out the openings for duct (A) and power cable (B), in cabinet or wall, according to the direction of discharge chosen. 1½’’ See figures at right. 7/8’’ NOTE: The duct opening width (A) is 4¼’’...
  • Page 6 3. PREPARE HOOD ( CONT'D Remove the 8 screws retaining the bottom panel to the hood and set aside. Slide out the bottom panel and set aside. NOTE: Wires not shown in illustration to ease understanding. CREW OCATIONS HO0159 ERTICAL ISCHARGE Go to step 3.11 on page 8.
  • Page 7 3. PREPARE HOOD ( CONT'D ORIZONTAL ISCHARGE CONT Turn the hood over and remove the metal shutoff plate from the back of the hood, by removing its 3 retaining screws. Set the screws aside. HO0169 Using a straight-blade screwdriver, remove the discharge knock-out. To ease removal, use a long nose pliers for the third step. See figures below.
  • Page 8 3. PREPARE HOOD ( CONT'D ERTICAL ISCHARGE 3.11 Turn the hood over and remove the metal shutoff plate from the back of the hood, by removing its 3 retaining screws. Set the screws aside. HO0169 3.12 Using a straight-blade screwdriver, remove the discharge knock-out. To ease removal, use a long nose pliers for the third step. See figures below.

  • Page 9: Install Adapter/Damper

    4. INSTALL ADAPTER/DAMPER The wall duct must be roughed-in to properly interface with the hood. Before performing the installation, make sure the adapter fits easily in the duct. If this hood replaces an existing hood, please note that location of the air exhaust can vary from one hood manufacturer to another.

  • Page 10: Install Hood

    5. INSTALL HOOD Run power cable to installation location. Position the hood in its intended location. Using a pen, mark the position of the screws (smaller part of the keyholes, see illustration below for the 5 keyholes locations). Remove the hood. Install 4 no.

  • Page 11: Reinstall Bottom Panel

    7. REINSTALL BOTTOM PANEL CAUTION Ensure not to pinch the wires when reinstalling the bottom panel. CAUTION Remove protective plastic film covering filters before installing them. Reinstall the bottom panel, using 9 screws saved from steps 3.4 and 3.5, as shown at right. NOTE: The left side panel will hide one screw.

  • Page 12: Operation

    9. OPERATION Always turn your blower on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. IGHTING NTENSITY PEED HC0016 A) Blower Delay switch D) OFF lighting switch...

  • Page 13: Use And Care

    10. USE AND CARE REASE FILTERS AND BOTTOM PANEL The grease filters and the bottom panel should be cleaned frequently. Use a warm detergent solution. Remove grease filters by pushing them towards the back of hood and rotating downward. Clean all-metal filters in the dishwasher using a non-phosphate a non-phosphate detergent.

  • Page 14: Service Parts

    Broan-NuTone recommends to contact a certified service depot for all replacement parts and repairs. HL0232 IDTHS...
