Hold the One Key Return button for 2 seconds. The quadcopter will beep and the tail light will
flash. The quadcopter will now return to the remote controller.
Hold the Headless Mode button for 2 seconds and you will hear the controller begin to beep,
indicating it has entered Headless Mode. No matter what direction the quadcopter faces, it will
respond according to the direction pushed on the remote. (Forward on the remote will make the
quadcopter fly forward.) This makes flying simpler and more convenient for beginner pilots. To exit
Headless Mode, press the button again and you return to Normal Mode.
Headless Mode X-axis Y-axis Calibration
Often times after turning on the remote, the axises will need to be calibrated. To calibrate the
X-axis, hold the X-axis calibration button for 3 seconds. The LED lights will flash until the quad is
level. Calibration is complete. To calibrate the Y-axis, hold the Y-axis calibration button for 3
seconds. The LED lights will flash until the quad is level. Calibration is complete. Reboot your
quad for calibration to take effect.
Problem
Quadcopter LED blinks for more than 4
seconds after battery is inserted. No
response to remote controller.
No response after battery is connected to
quadcopter.
Motor does not respond to remote, LED
flashes.
Main rotor continues to spin after landing.
Main rotor spins but unable to takeoff.
Quadcopter strongly vibrates.
Tail still off trim after adjustments, or
inconsistent speed during sideways
flying.

One Key Return

Headless Mode

Troubleshooting

Cause
Unable to sync quadcopter and remote.
1. No power to remote or drone.
2. Low battery power.
3. Poor contact on battery terminals.
Helicopter battery is drained.
Throttle trim accidentally increased during
flight.
1. Rotor deformation
2. Quadcopter battery is drained.
Rotor deformation
1. Damaged tail rotors
2. Damaged tail drive motor
10
Solution
Repeat syncing process. (See p 7)
1. Turn on remote, properly insert drone
battery
2. Charge battery
3. Re-seat batteries properly
Fully charge batteries.
Confirm throttle trim is in the center or
slightly below.
1. Replace main blades.
2. Fully charge batteries.
Replace the rotor.
1. Replace the rotor.
2. Replace the main motor.
