Name
EGR pipe bolt
(to air duct)
EGR pipe bolt
(to EGR cooler)
Idler pulley/tensioner
pulley
Glow plug
Vacuum pump
Timing gear case cover
Cylinder head cover
Oil dipstick gauge cover
Oil filter cap
Fuel rail
Injector clamp bolt
High pressure pipe
(between high pressure
pump and fuel rail
assembly)
High pressure pipe
(between fuel rail assembly
and injector)
Crankshaft position
sensor
Main wiring
Intake duct
Power steering pump
Cylinder head front
cover
Ladder frame
Numbers of
Size
fastener
M6×16
2
M8×25
2
1
M5 4
M6×25
3
M6×40
7
M6×45
1
M6×50
3
M6×35
21
M6×16
1
1
M8×25
2
M6×44
2
M17 1
M17 4
M5×14
1
M6×16
5
M8×25
4
M8×100
3
M6×10
5
M8×35
5
0000-00
Note (total
Tightening
tightening
torque (Nm)
torque)
10±1Nm
-
25±2.5Nm
-
45±4.5Nm
-
20±2Nm
-
10±1Nm
-
10±1Nm
-
10±1Nm
-
10±1Nm
-
10±1Nm
-
10±1Nm
-
25±2.5Nm
-
25±2.5Nm
-
9±1.0Nm
-
130˚±10˚
30±3Nm
-
30±3Nm
-
8±0.4Nm
-
10±1Nm
-
25±2.5Nm
-
25±2.5Nm
-
10±1Nm
-
30±3Nm
-
