Scotsman KDIL-PN-ID3 Instruction Manual

Download this manual

Kit Number: KDIL-PN-ID3

Kit Purpose: To lower the ice level in an ED300 ice dispenser when a Scotsman

Nugget ice machine is stacked on top of the dispenser.

Kit Contents:

Bin thermostat

KDIL-PN-ID3

11-0353-23

Applications & Other Requirements:

• N0422, N0622, N0922 or N1322 onto ED300. Also requires Cornelius adapter and

agitator kit.

Installation Sequence:

1. Agitators

2. Diverting plates

3. Adapter

4. Ice separator and thermostat bracket

5. Ice machine

6. Thermostat

Instructions

Baffle/cap tube bracket, grommets & fasteners

included

Wire

included

17-3301-01

Page 1 Instructions Kit Number: KDIL-PN-ID3 Kit Purpose: To lower the ice level in an ED300 ice dispenser when a Scotsman Nugget ice machine is stacked on top of the dispenser. Kit Contents: Bin thermostat Baffle/cap tube bracket, grommets & fasteners Wire...
Page 2 4. Install triangular separator into adapter per its instructions. 5. Attach thermostat bracket to separator, using bolts from the Scotsman kit. Bracket mounts inside of front separator flange, and it angles back to the dispenser. Be sure grommets are installed onto bracket's lower holes.
Page 3 14. Open the control box door. Locate the blue wires connected together with an insulted double male quick connect. Disconnect the blue wires at the quick connect. 15. Route the blue wires thru the snap bushing the bottom of the control box and connect them to the thermostat.
Page 4 Figure A: Route Cap Tube Thru Hole In Separator Thermostat Cap Tube Mounting Bracket Figure B: Route Cap Tube in Thermostat Bracket...
