Page 1: User Manual
Camera lntegrared speed dome Installation and user manual Before Dome integrated camera, please read this manual... - Page 2 1、 User be notified to Thank you for purchasing the company products! According to the instructions of the Company's warranty during the warranty period, the failures of the product under normal use, the product by the company for free repair or replacement parts. Without the company's agreed to not disassemble the repair.
- Page 3 maintenance: 1, without the permission of their own overhaul and modification caused by the malfunction of the device and damage; 2, transit, manual unloading and damaged; 3, not the product user manual requires the use, maintenance, maintenance and damage caused by crashing, crushing, water, moisture, corrosion and other man-made causes damage;...
- Page 4 more smoothly, life is also longer. imported belt drive, a more stable operation more reliable and no noise. using imported stepper motor, horizontal speed of 40 ° / sec. Taiwan high-power 12 W dot infrared light, infrared light irradiation using a variety of angles so that a more uniform, the actual effective distance up to 120 meters.
- Page 5 angular velocity: Infrared speed of the ball: 360 degrees horizontal rotation 40 ° / sec, fourth gear horizontal scanning speed is adjustable; vertical of +3- -90 degrees rotated 30 ° / sec IR High Speed Dome: 360 degrees horizontal rotation of 220 °...
-
Page 6: Installation And Connection
IR High Speed Dome: Horizontal 0.1 ° / sec to 220 ° / sec Rotation limit: the level the PTZ rotation angle of 360 degrees within the adjustable software / optical limit Allow camera + Lens size: 9 inch ball: 120mm (L) x 60 (H) x 60 (W) 3, the environmental indicators Operating Temperature: -35 °... -
Page 7: Address Settings
1）. Address settings An 8-bit DIP switch B1 1-8 bit address code for infrared ball set, in the range of 1 to 255 address code, address code of each ball with DVR or matrix or control keyboardaddress code, in order to achieve control. Binary 8-bit DIP switch is used to set the address code, each dial to ON when the value of 1 to OFF value is 0, the address shown in Table 2。... -
Page 8: Baud Rate Setting
11100000 01101000 10100100 00101100 00010000 11101000 01100100 10101100 10010000 00011000 11100100 01101100 01010000 10011000 00010100 11101100 11010000 01011000 10010100 00011100 00110000 11011000 01010100 10011100 10110000 00111000 11010100 01011100 01110000 10111000 00110100 11011100 …………… 00111100 10111100 01111100 11111100 …………… 00011111 10011111 01011111 11011111 00111111... -
Page 9: Feature Set
6：Feature set： 1 set / call the preset position The preset function is called by the control device settings / infrared ball horizontal angle, vertical angle position parameters stored in digital form to the infrared ball, you need to call these parameters can be adjusted to the infrared ball preset position setup . - Page 10 Example: Using a model control keyboard tune preset 1 a call a preset key, and then enter the "1" key Click 'OK' key 2, automatic inspection line call / Clear Automatic inspection is set by the operation of any cruise line, only one external command allows the ball inspections are carried out automatically by the designated routes, and can stay in the corresponding preset.
- Page 11 adjustable. Mode of operation through the control keyboard, hard disk recorders implementation set 51 preset dwell time of 2 seconds; "set 52 preset dwell time is 4 seconds; dwell time is set for auto scan command relationship is shown in Table 5. Table 5: automatic inspection preset residence time command relational tables Residence...
- Page 12 Inspection Corresponding Invoke the command Clear command of the line preset number NO.1 Call preset 41-bit Set preset 41-bit 1—16 Call preset 42-bit Set preset 42-bit 17—32 NO.2 Call preset 43-bit Set preset 43-bit 65—80 NO.3 NO.4 Call preset 44bit Set preset 44-bit 113—128 NO.5...
- Page 13 limit set. Ball machine can only operate between these two points. Example: using a model to control the keyboard to the left and right limit set a set preset key, then move the control the the rocker ball machine to the right limit position b, enter "35"...
- Page 14 b click "OK" button. (4) Auto Pan speed setting Horizontal speed of the ball when the automatic scanning of the infrared fourth gear adjustable. Mode of operation through the control keyboard, hard disk recorders implementation set presets 64-bit scanning speed of 40 °...
-
Page 15: Camera Menu Settings
b click "OK" button. 7、Camera menu settings A: Open the camera menu: press the the "Aperture key to open the menu by controlling the keyboard, hard disk recorders and other control equipment; prefabricated 95-bit" is called to open the camera menu. b: "Zoom"... - Page 16 a normal phenomenon, because it does not shine infrared light irradiation angle and the current lens viewing angle does not match, it is in a resting state; 7: The machine with the ordinary high-speed ball preset also with lens preset setting method please refer to "presets" 8: ball machine outlet in order to avoid the connector outlet for the high temperature of the conductive ring line, please do not force to pull the output cable.
