Back Panel Description

Antenna Connectors (1-2): SMA antenna connectors.
Attach the included high gain dual band antennas to these connectors
WPS: Hold down for 3 seconds to enable WPS push button configuration.
Reset: Push down once to reboot the Dual Band Wireless Router. Hold
down for 5-10 seconds to reset the Dual Band Wireless Router back to
factory settings.
Power: Power adapter port. AC Input: 100-240V, DC Output: 5V 2A
USB Port: Attach USB storage devices, such as USB flash drives and
external hard drives, for file sharing.
Wired Devices: Gigabit RJ-45 ports for connecting to wired computers or
network devices.
Modem: RJ-45 port for connecting to your Broadband Modem.
