LED Indicators

Power: Indicates when the Dual Band Wireless Router is powered on. The
LED will remain on.
5.0GHz Wireless Activity: Blinks rapidly when wireless data traffic is
transmitted or received over the 5.0GHz wireless network.
2.4GHz Wireless Activity: Blinks rapidly when wireless data traffic is
transmitted or received over the2.4GHz wireless network.
WPS: Wi-Fi Protected Setup activity. When the WPS mode is activated the
WPS LED blinks as it awaits a connection.
USB Connection: Indicates when a USB storage device is connected to the
USB port for local sharing.
Gigabit Wired Ports 1-4: Indicates when a networking device is connected to
a wired port on the back of the Dual Band Wireless Router. The LED blinks
rapidly when wired data traffic is transmitted or received.
Internet Connection: Indicates when the Dual Band Wireless Router is
connected to a broadband modem. The LED will blink when Internet traffic is
transmitted or received.
