Workhorse LG 25 DSS Assembly / Operation Instructions / Parts

LG 25 DSS
*This sprayer is designed to be attached to a stable surface.
— GENERAL INFORMATION
The purpose of this manual is to assist you in assembling, operating
and maintaining your lawn and garden sprayer.
Please read it carefully as it furnishes information which will help you
achieve years of dependable trouble-free operation.
— WARRANTY / PARTS / SERVICE
Products are warranted for two years from date of manufacture
against manufacturer or workmanship defects.
Your authorized dealer is the best source of replacement parts and
service. To obtain prompt, efficient service, always remember to
give the following information: 1) Correct part description and part
number. 2) Model number and serial number of your sprayer.
Part description and part numbers can be obtained from the
illustrated parts list section of this manual.
Whenever you need parts or repair service, contact your distributor
/ dealer first. For warranty work always take your original sales slip,
or other evidence of purchase date, to your distributor / dealer.
— ASSEMBLY INSTRUCTIONS
Tools required:
1 — 9/16" End Wrench
1 — Thread Sealant
WARNING: Some chemicals will damage the pump valves if allowed to soak untreated for a long period of time.
Always flush the pump with water after use. Do not allow chemicals to sit in pump for extended times of idleness.
Follow chemical manufacturers instructions on disposal of all waste water from the sprayer.
PRECISION SPRAY EQUIPMENT, a divison of Green Leaf, Inc. 9490 N BALDWIN ST FONTANET, IN 47851 www.workhorsesprayers.com
WORKHORSE
WORKHORSE
Assembly / Operation Instructions / Parts
S P R A Y
by PSE, a Division of Green Leaf, Inc® by PSE, a Division of Green Leaf, Inc®
MODEL # LG 25 DSS
25 GAL. DELUXE SPOT SPRAYER
• Polyethylene Tank
• 12 Volt Diaphragm Pump
• 2.0 G.P.M.
• Lever Handgun
• 15 Ft. of 3/8" Hose (Handgun)
• Pressure Gauge
• Adjustable Pressure Range (0-60 PSI Max.)
— OPERATION
The pumping system draws solution from the tank, through
the strainer and to the pump. The pump forces the solution
under pressure to the boom nozzles and spray wand.
The pump has a pressure switch which will shut the pump off
when it reaches 60 PSI.
Pressure may be regulated by opening or closing the valve
located on the top of the tank. See "Valve Operation" illustrated in
this manual.
Regularly inspect the suction supply screen on the inside
of the tank. Flush with water to clear any accumulated debris.
— AFTER SPRAYING
After use, fill the sprayer part way with water. Start the sprayer
and allow clear water to be pumped through the plumbing system
and out through the spray nozzles.
Refill the tank about half full with plain water and use a chemical
neutralizer such as Nutra-Sol® or equivalent and repeat cleaning
instructions. Flush the entire sprayer with the neutralizing agent.
Follow the chemical manufacturer's disposal instructions of all
wash or rinsing water.
— WINTER STORAGE
Drain all water and chemical out of sprayer, paying special atten-
tion to pump and valves. These items are especially prone to
damage from chemicals and freezing weather.
The sprayer should be winterized before storage by pumping a
solution of RV antifreeze through the entire plumbing. Proper care
and maintenance will prolong the life of the sprayer.
