Electrical Parts List (230V) - Infinity Overture 2 Service Manual

Overture 2
Part#
SEMICONDUCTORS
DI1186
DI1224
IC1045
IC1215
IC1216
TR1304
TR1002
TR1017
TR1316
TR1317
TR1318
DI1060
DI1003
DI1004
604-L469EGW
CAPACITORS
CP1126
CP1656
CP1659
CP1661
CP1662
CP1663
CP1664
CP1666
CP1669
CP1672
CP1673
CP1674
CP1675
CP1677
CP1804
CP1805
CP1806
CP1807
CP1828
CP1829
CP1658
CP1897
CP1904
RESISTORS
RS2369
RS2296
RS2301
RS2151
RS2464
RS2025
RS2370
RS2139

Electrical Parts List (230v)

Description
Diode Zener 36V 5% 5W T/R
DIODE PWR RECT 800V/3A
Three-Term. Adj. Pos. V R LM317T
IC TL064CN Quad OP AMP
IC TL062CP Dual OP Amp.
Transistor NPN 60V/3A 25W 2SD2012
Transistor NPN TO-92 2N3904
Transistor PNP T/R 2N3906
Xsistor ZTX658 NPN
Xsistor ZTX758 PNP
Pwr Mosfet STH16NA40FI
Diode Switching 500mW 75V
Diode Rectifier 1N4004
DIODE ZENER 6.2V 1/2W T/R
Led Green/Red Common Cath
CAP POLY FILM 1uF 10% 50V
Cap. Al El 100uF 20% NPE
Cap. NPE 10uF 20% 25V T/R
Cap. Alum El. 100uF 20% 5
Cap. Alum El. 10uF 20% 35
Cap. Alum El. 47uF 20% 25
Cap. Alum EL. 4.70uF 20%
Cap Cer Disc 68pF 20% 500
Cap. Poly Fil .10uF 10% 4
Cap Poly 0.22uF 5% 63V T/
Cap. Pol Fil 1nF 10% 50V
Cap. Alum El. 1uF 20% 50V
Cap. Pol Fil 0.1uF 5% 50V
Cap Poly 0.033uF 5% 50V T
Cap Alum El 270uF 400V
Cap Alum El 22uF 20% 100V
Cap Poly Fil 0.22uF 10% 4
Cap Al El 22uF 20% 250V
Cap Alum El 390uF 20% 200
Cap Al El 4.7uF 20% 100V
Cap. Disc 100pF 10% 500V
CAP AE 2200uF 20% 25V
CAP POLY 0.022uF 20% 250V
POTENTIOMETER 1Kohm BIAS ADJ
RES M/O F/P 62Kohm 5% 2W
Res Fuse 0.47 ohm 5% T/R
RES M/O F/P 1Kohm 5% 2W
RES W/W 20Kohm 5% 6W T/R
RES M/F 9.31Kohm 1% 1/4W
RES M/F 37.4Kohm 1% 1/4W
RES M/F 200 ohm 1% 1/4W
24
Qty
1
1
1
2
1
1
3
4
3
1
2
8
2
1
1
1
1
1
1
5
1
1
2
1
3
1
1
5
1
1
1
1
1
1
1
3
1
1
1
2
2
1
1
1
1
1
