I
2.6
p
NTERMEZZO
Owner's Guide

Advertisement

loading

Related Manuals for Infinity Intermezzo 2.6p

Summary of Contents for Infinity Intermezzo 2.6p

  • Page 1 ™ NTERMEZZO Owner’s Guide...
  • Page 2 Infinity has designed, to the same standards listening evaluations and our rigorous engineering standards, as for Intermezzo 2.6p, a matching 3-way center-channel result in a loudspeaker that realistically and accurately reproduces loudspeaker and a 12, "...
  • Page 3 Home Theater System Generally, the system should be placed at least three feet away from the side walls.The Intermezzo 2.6p should be placed on strong, rigid speaker stands that place the tweeter at ear level. In 2-channel applications, the two speakers should be equidistant IGURE from your primary listening position.
  • Page 4 TANDARD IRING (One Channel Shown) Amplifier/Receiver Speaker Outputs INTERMEZZO 2.6p RED = STRIPE = Made in USA 8 Ohm Nominal Impedance Recommended Amp Power 25-250W 1. LOOSEN TERMINALS 2. INSERT BARE END; TIGHTEN TERMINALS IMPORTANT: The high-frequency (HF) and low-frequency (LF) sections are joined by strapping bars.The strapping bars must remain in position for proper operation with standard wiring.
  • Page 5 IRING The Intermezzo 2.6p’s outer connection panel and internal dividing network are designed so that separate sets of speaker cables can be attached to the low-frequency transducer and midrange/high- frequency transducer portions of this dividing network.This is called bi-wiring. Bi-wiring can provide several sonic advantages and considerably more flexibility in power amplifier selection.

  • Page 6: Specifications

    ® (See Appendix, p. 7, for wall-mounting instructions.) Infinity continually strives to update and improve existing products, as well as create new ones.The specifications and construction details in this and related Infinity publications are therefore subject to change without notice.

  • Page 7: Important Safety Note

    While holding speaker, tighten the Adjustment Bolt until the Socket-Cup Jaws hold the speaker Turn the Intermezzo 2.6p bookshelf speaker upside down assembly securely in place. Adjust Arm to desired speaker and attach the Speaker Mount to the base of the speaker with position and tighten the lower bolt.
  • Page 8 © 2001 Infinity Systems, Inc., 250 Crossways Park Drive, Woodbury, NY 11797 USA (800) 553-3332 (USA Only) *Trademarks of Dolby Laboratories.THX name and logo are © Lucasfilm Ltd. & trademarked. All rights reserved. Used under authorization. OmniMount is a registered trademark of OmniMount Systems, Inc.
