Mechanical/Packaging Parts List - Infinity Overture 2 Service Manual

Overture 2

Mechanical/Packaging Parts List

Ref No.
1 CABINET
2 6.5", WOOFER, B160-4 (120V) DCR = 14.2Ω±10%
6.5", WOOFER, LM-B160-8 (230V) DCR = 40Ω±10%
3 SCREW, #8 x .75", PPH, ZINC
4 REAR WOOFER GRILLE
5 FRONT/REAR WOOFER BAFFLE
6 AMPLIFIER CAP
7 CROSSOVER NETWORK (120V)
8 BASE, FRONT FOOT
9 REAR BASE
10 REAR BASE w/PORT
11 BINDING POST (RED)
12 BINDING POST (BLACK)
13 SCREW, #8 x 1" PPH, ZINC
14 SCREW, #6-32 x 3/8" PPHMS CADCAD PLATED
15 AMPLIFIER
16 1" (25MM) NEODYMIUM TWEETER DCR = 3.6Ω±10%
17 UPPER FRONT BAFFLE (120V)
UPPER FRONT BAFFLE (230V)
18 FRONT GRILLE
19 SCREW, #6 x 3/4" PPHD, BLK
20 SCREW, 4-40 x .25" PPH, ZINC
21 5.25",MIDRANGE TRANSDUCER, B125-6 DCR = 7.7Ω±10%
22 MIDRANGE CUP (120V)
PACKAGING
23 SPIKE FOOT SET, 1.5"
24 OUTER CARTON (120V)
25 FOAM PAD, TOP
26 FOAM PAD, BOTTOM
27 SURVEY CARD
28 OWNER'S MANUAL (120V)
29 SAFETY SHEET
30 LINE FUSE 5A 2AG SLO-BLO (120V)
Description
11
Qty Part No.
NOT FOR SALE
2 330618-001
2 333773-001
17 900102-012
1 330955-001
2 332334-001
1 331399-001
1 331235-001
1 331184-001
1 331075-002
1 331236-001
1 331723-001
1 331724-001
15 900102-016
2 10811
1 NOT FOR SALE
1 333232-001
1 331182-001
1 332335-002
1 333585-001
12 63563
2 905502-004
2 330650-001
1 330833-001
1 331360-001
1 331245-001
1 331254-001
1 331255-001
1 330033-001
1 332292-001
1 330100-001
2 FS1068 or 331925-001
