EPS 7000 Single Module
1.5
Single Module Indicators and Controls
Single Module indicators and controls are located in three places on the UPS cabinet: on the front panel, behind a
drop-down cover just below the front panel, and inside the cabinet doors, see Figure 1-7. In battery cabinets and
auxiliary cabinets, the controls are located behind the cabinet doors.
The following display descriptions:
◗
Front Panel
◗
Alphanumeric Display
◗
Hidden Panel
Figure 1-6: EPS 7000 Front Panel Indicators and Controls.
page 1 — 6
Front Panel
Alphanumeric
Display
Hidden Panel
Cover Plate
Introduction
