EPS 7000 Single Module
1.3

General Description

EPS 7000 is a family of compact, high-efficiency uninterruptible power systems. Standard power ratings for single-
module systems range from 300 to 500 kVA.
computer-type loads. Computer-aided UPS diagnostics and modular construction assures that any required service
on the UPS can be identified and completed rapidly. Remote system monitoring, remote annunciation of UPS
performance signals, and telecommunication capabilities allow total control of the UPS by the user.
The EPS 7000, SSC, battery, and all auxiliary equipment is listed for safety by Underwriter's Laboratories, Inc. (UL)
under UL Standard 1778 and under Canadian Standards Association (CSA) standard C22.107.
Major components of the EPS 7000 Single Module include:
◗
UPS Single Module
◗
UPS maintenance bypass cabinet
◗
UPS bypass cabinet
◗
Battery disconnect
Each of these cabinets is described below. Figure 1-1 shows a single-module UPS.
Figure 1-1: EPS 7000 System, Single-Module Configuration, 1 GCC per Module.
page 1 — 2
EPS 7000 are optimized for compatibility with non-linear
Introduction
