Page 1: User Guide
United Kingdom User Guide Condensing Central Heating Boiler Promax SL 12 - 15 - 18 - 24 Please keep these instructions in a safe place. If you move house, please hand them over to the next occupier. -
Page 2: Table Of Contents
Contents Section Page Natural Gas Operating the Boiler Potterton Promax SL 12 Heat ErP Troubleshooting G.C.N 41 592 34 Potterton Promax SL 15 Heat ErP G.C.N 41 592 35 Clearances Potterton Promax SL 18 Heat ErP G.C.N 41 592 36... -
Page 3: Operating The Boiler
1.0 Operating the Boiler In Operation 1. The Potterton Promax SL Heat is a range of high efficiency condensing boilers. 2. In common with other condensing boilers its exceptional efficiency means the flue gases are cooled to such an extent that steam is often visible at the outside flue terminal. -
Page 4: Troubleshooting
Boiler not working 2.0 Troubleshooting START Make sure the gas Is there electricity to the Ignition Spark will commence supply is turned ON boiler ? and check if other gas appliances are operating (e.g. fire, Boiler flame established cooker). (Check that a flame is visible through the sight glass) Check electrical supply to boiler is switched on. - Page 5 2.0 Troubleshooting Is the Room Thermostat (if Is the Timer ON and fitted) set high enough ? calling for heat ? Typical examples of external timer CH OFF CH ON Turn Room Thermostat to maximum setting (typical example shown) Ensure timer is set for Central Heating ON (see any instructions supplied with timer) If you don’t know what you need to do...
-
Page 6: Clearances
3.0 Clearances 390mm 5mm Min 5mm Min For your Safety NOTE: Only qualified persons are authorised to assemble, install and maintain the installation. 200mm 1. This appliance must have been installed in accordance with the manufacturer’s instructions and the regulations in force. -
Page 7: Care Of The Boiler
4.0 Care of the Boiler Cleaning the Outercase 1. The painted panels should be wiped with a damp cloth and then dried completely. DO NOT USE ABRASIVE CLEANING AGENTS. Frost Protection 1. The boiler does not have integral frost protection. It is recommended that the installer fits a suitable protection device to the system controls if required. -
Page 8: Legislation
6.0 Legislation Installation, Commissioning, Service & Repair 1. This appliance must be install in accordance with the manufacturer’s instructions and the regulations in force. Read the instructions fully before installing or using the appliance. 2. In GB, this must be carried out by a competent person as stated in the Gas Safety (Installation &... -
Page 9: Warranty & Service
7.0 Warranty & Service General To make sure your boiler warranty is activated and maintained, it is essential that the: 1. Benchmark checklist is completed by your installer 2. Warranty is registered with Baxi 3. Boiler has an annual service Please note that failure to adhere to terms and conditions will make your warranty invalid. - Page 10 7.0 Warranty & Service Annual Service A service must be completed every 12 months from the date of installation to maintain your warranty. This service must be completed by one of the following: • A Gas Safe registered installer/engineer • Baxi Customer Support;...
-
Page 11: Erp Information
1.0 Introduction 8.0 ErP Information Product Fiche - Boiler Space Heaters Product fiche for boiler space heaters Potterton Promax SL Heat ErP Seasonal space heating energy efficiency class Rated heat output (Prated or Psup) Seasonal space heating energy efficiency Annual energy consumption... - Page 12 8.0 ErP Information Package Fiche - Boilers Package fiche for boilers indicating the space heating energy efficiency of the package fi f ‘I’ I I I Class IV = 2%, Class V = 3%, Class VI = 4%, c fi Class VII = 3.5%, Class VIII = 5% c fi...
- Page 13 (1) The intermediate values are calculated by linear interpolation between the two adjacent values. (2) Prated is related to the preferential space heater or combination heater. Package efficiency Potterton Promax SL Temperature control X Temperature control Y © Baxi Heating UK Ltd 2015...
-
Page 14: Emergency
9.0 Emergency Warning ! If you smell gas Do not operate light switches Do not operate any electrical equipment Do not use a telephone in the hazardous area Extinguish any naked flame and do not smoke Open windows and doors in the hazardous area Turn off the gas supply at the meter Warn any other occupants and vacate the premises Telephone the National Gas Emergency Service on:-... -
Page 15: Notes
10.0 Notes © Baxi Heating UK Ltd 2015... - Page 16 Baxi Customer Support 0344 871 1525 Opening hours Monday - Friday, 8.00am-6.00pm Weekends and Bank Holidays, 8.30am-2.00pm Please note calls may be recorded for training and monitoring purposes baxi.co.uk Register now to activate your warranty: www.baxi.co.uk/registration For the warranty to be maintained, please make sure... Benchmark checklist is completed Warranty is registered with Baxi The boiler has an annual service...
