QUICK START GUIDE
Amie
™
Precision Studio Monitor
stereo
1–3 meters
For optimum stereo
listening, form an equi-
lateral triangle between
the loudspeakers and
listening position.
listen on tweeter axis
For optimum listening,
place tweeter at ear
level. For loudspeakers
mounted above head,
aim cabinets toward the
listening position.
what's in the box?
•
Documentation envelope, including this Quick Start Guide, Loudspeaker Safety
Instructions, Declaration of Conformity, FCC and Canadian Statements, and
Meyer Sound Product Warranty card
•
U.S. AC power cable, powerCON 20-to-NEMA 5-15P, 3 m, 14 AWG, PN 27.084.058.01
•
E.U. AC power cable, powerCON 20-to-CEE 7, 2.5 m, 1.5 mm
•
powerCON 20 cablemount connector (for wiring AC looping cables), PN 466.047
•
(2) 3/8-16 x 0.75-inch hex screws (for side attachment points), PN 101.526
•
(2) 3/8-inch flat washers (for side attachment points), PN 113.542
1–3 meters
1–3 meters
5.1
LFE
30°
110°
For optimum 5.1 listening,
place loudspeakers equi-
distant (1–3 meters) from
the listening position.
optional m-mub u-bracket
•
Mounts on walls or ceilings
•
Suspends from "C" or "G" hanging clamps
with standard 1/2-inch or 12 mm bolts
•
Mounts on 1 3/8-inch poles
•
Three loudspeaker attachment points
included for variable distances from
mounting surfaces and poles
C I N E - S T U D I O
2
, PN 27.115.033.01
C
30°
110°
