  • Page 1 METROLOGIC INSTRUMENTS, INC. ® TECH 10 ASER (1070) ROJECTION CANNER ’ NSTALLATION AND UIDE November 2004 Printed in USA 0 0 - 0 2 1 6 6 A...
  • Page 3 Copyright © 1999 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review, or provided for in the Copyright Act of 1976.
  • Page 4: Table Of Contents

    Introduction ... 1 Scanner and Accessories ... 1 Scanner Connections to the Host ... 2 Configuration of the Scanner to the Host System... 3 Parts of the Scanner ... 4 Installation of the Stand ... 5, 6 Labels ... 7 Scanning Bar Codes ...
  • Page 5: Introduction

    Water- resistant, shock-resistant, and rugged, the TECH 10 scanner is also fast, aggressive and reliable. It can register bar codes at a range of 203 mm – 559 mm (8" - 22") and can autodiscriminate among all common codes.
  • Page 6: Scanner Connections To The Host

    1. Turn off the host system. 2. Locate the 19-pin female end of the scanner link cable and find the widest key located above pins L and A. Align this key with the corresponding key on the scanner box’s Mil spec connector. While pushing in on the connector, rotate the ring clockwise until it locks into place with a click.
  • Page 7: Configuration Of The Scanner To The Host System

    Scanner Programming Guide by an asterisk that appears before the brief definition next to the bar code. In order for the scanner to communicate with the host system properly, it needs to be programmed to meet your specific scanning needs. Since each host system is unique, the scanner must be configured to match the host system requirements.
  • Page 8: Parts Of The Scanner

    ARTS OF THE CANNER Becoming familiar with the features of the TECH 10® scanner will help when operating the scanner. The following illustration and list explain the pertinent parts. 1. Green and Red LEDs 2. Laser Output Window 3. Mil spec Connector...
  • Page 9: Installation Of The Stand

    2. Lay the stand on top of the scanner with the angled bracket pointing up and toward you. 3. Align the four clearance holes to the four holes in the scanner’s case. Fasten the stand to the scanner by inserting the four 6-32 x ½" screws into the four holes in the scanner’s case.
  • Page 10 Figure 2...
  • Page 11: Labels

    ABELS A label is inside the window of the scanner noting that this device is a CDRH Class IIA laser product and IEC 825 LASERKLASSE 1. Also, on the scanner is a label on the back of the unit. This label contains information such as the model number, date of manufacture, and serial number.
  • Page 12: Maintenance

    AINTENANCE Smudges or dirt that appears on the scanner window can interfere with proper scanning. Therefore, only maintenance required is an occasional cleaning of the glass window. 1. Spray glass cleaner onto lint free, non-abrasive cleaning cloth. 2. Gently wipe the scanner window.
  • Page 13: Specifications

    PPENDIX Specifications Application: Universal Industrial Scanner Light Source: Visible Laser Diode 650 ± 5nm Laser Class: CDRH: CLASS IIa; EN 60825 Class 1 Certifications: CE, UL listed for US and Canada EMC: FCC, ICES-003 & EN 55022 Class A Mechanical...
  • Page 14 A (C PPENDIX ONTINUED Operational Depth of Scan Field: Scan Speed: Scan Pattern: Exit Angle: Indicators: Beeper Operation: Maintenance Required: Decode Capability: System Interfaces: Print Contrast: Roll, Pitch, Yaw: Environmental Storage Temperature: Operating Temperature: Humidity: Light Levels: Ventilation: Shock: ESD: Contaminants: Specifications subject to change without notice.
  • Page 15: Pin Assignments For The Mil Spec Connector

    Pin Assignments for the Mil spec Connector Each TECH 10®scanner has a 19-pin male Mil spec connector that is on the side of the unit. To connect the scanner to the host device, use a communication cable with a female Mil spec connector. The communication cable may include a power transformer or it may be designed to draw power directly from the host device.
  • Page 16: Limited Warranty

    ANY LIABILITY OF METROLOGIC EXCEED THE ACTUAL AMOUNT PAID TO METROLOGIC FOR THE PRODUCT. METROLOGIC RESERVES THE RIGHT TO MAKE ANY CHANGES TO THE PRODUCT DESCRIBED HEREIN. USA Corporate Headquarters Metrologic Instruments, Inc. 90 Coles Road Blackwood, NJ 08012-4683 Customer Service: 1-800-ID-METRO Tel: 856-228-8100 Email: info@metrologic.com...
  • Page 17: Notices

    Under no circumstances should the customer attempt to service the laser scanner. Never attempt to look at the laser beam, even if the scanner appears to be nonfunctional. Never open the scanner in an attempt to look into the device.
  • Page 18: European Standard

    PPENDIX CONTINUED UROPEAN TANDARD Warning This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Funkstöreigenschaften nach EN 55022:1998 Warnung! Dies ist eine Einrichtung der Klasse A. Diese Einrichtung kann im Wohnbereich Funkstörungen verursachen; in diesem fall kann vom Betrieber verlangt werden, angemessene Maßnahmen durchführen.
  • Page 19: Appendix E Patents

    Appendix E Patents “Patent Information This METROLOGIC product may be covered by one or more of the following U.S. Patents: U.S. Patent No. 4,360,798; 4,369,361; 4,387,297; 4,460,120; 4,496,831; 4,593,186; 4,607,156; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,923,281; 4,933,538; 4,960,985; 4,992,717; 5,015,833;...
