Weego JS6 standard Quick Start Manual page 2

Learn about Your Weego Jump Starter!
Jump Start Socket
14V/1A Input Port
LED Flashlight
5V/2A Micro USB Input Port
5V/2A USB Output Port
Quick Start Guide – ready, Get Set, Jump Your Vehicle!
1. Read vehicle owner's manual: The vehicle manufacturer may have specific
cautions and instructions about jumping your vehicle of which you should
be aware.
2. If available, you should wear safety glasses and gloves while jumping
your vehicle.
3. If you are not in a well-ventilated area, please do not attempt to jump start
your vehicle.
4. Make sure your Weego has at least 2 indicator lights illuminated.
5. Remove any and all USB and/or charging devices connected to the Weego.
6. Put your vehicle in PARK and engage the emergency brake.
7. Make sure the vehicle battery terminals, jumper cables and Weego battery
pack are free of any moisture.
8. Turn off ALL electronics in your vehicle (air conditioner, heat, radio, lights,
chargers, etc.) to ensure optimal performance of your Weego.
9. Ensure key is in the "OFF" position in the ignition. For smart-key fobs (push-to-
start vehicles), make sure the vehicle is completely "OFF" before jump starting.
10. Check battery terminals for buildup. If buildup is present try to clean off
terminals with a wire brush or a dry cloth. A clean terminal will provide the
best conductivity between your clamps, vehicle battery,
and vehicle (figure 1).
11. Identify the positive and negative terminals on your ve-
hicle's battery. The positive terminal will usually be labeled
with a (+) and/or with a red coloring (figure 2).
12. Do not attach clamps to Weego yet! First, securely attach
the black clamp to the vehicle's negative (-) battery ter-
minal, then the red clamp to the vehicle's positive (+) bat-
tery terminal. Make sure the copper teeth of the clamps
are making good contact with the battery terminals for an
optimal connection.
13. Make sure the Weego is OFF.
On/Off Switch
14. Securely fasten the clamps into your Weego. Check that
Indicator Lights
you have a secure connection between the terminals and
clamps, and between the clamps and Weego (figure 3).
3
Start
5
Engine
18. After a successful start, quickly detach the Weego from
the clamps.
19. Detach the clamps from the vehicle (figure 7).
20. You are now able to drive your vehicle. You should be sure
to run your vehicle for at least 15 minutes before shutting
it off again. If you have engaged the emergency brake,
disengage before driving your vehicle.
15. Place the Weego in a secure loca-
tion so it will not fall when starting
the vehicle.
16. Power ON your Weego (figure 4).
17. Start your vehicle (figure 5).
Turn
4
Unit On a. If after 3 seconds engine does not
start, turn key to OFF position.
b. Detach the Weego from the
clamps. Wait 60 seconds and then
follow steps 13-20. If problems still
persist, please see the
Troubleshooting section in your
6
Weego Owner's Manual for other
possible causes (figure 6).
1
Red +
2
Red +
7
