Fig. 8
Shelf Installation
1- Position and affix rubber pads (C) (included) at each corner on the bottom of the unit (Fig. 9).
2- Place unit in desired location.
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A.
IIeBridge4SK
- 12 -
eBridge4SPT Chassis Mechanical Drawing & Dimensions (H x W x D approx.):
1.7" x 5.23" x 8.93" (43.18mm x 132.84mm x 226.82mm)
A
Fig. 9
B
Mounting Hardware
(Included):
Four (4) rubber pads
C
I25O
Left side
C
Rubber Feet
MEMBER
eBridge4SK
