eBridge100SPR - EoC Receiver
eBridge4SPT - 4 Port PoE/PoE+ EoC Transceiver Switch
The eBridge4SK kit consists of eBridge100SPR and eBridge4SPT which are Coax to CAT-5 Ethernet adapters/media converters that deliver data and power over
coax cable. eBridge4SK enables fast 10/100 Base-T Ethernet digital communication. eBridge4SPT allows you to upgrade your existing infrastructure by replacing
a single analog device with up to four (4) PoE/PoE+ devices. eBridge100SPR passes data and sends power over the coax to the eBridge4SPT. Data transmission
and power over the Coax are possible up to 300m. Maximum range from head end to the PoE camera/device is 610m, taking into consideration that up to 100m
of structured cable may be deployed at each end. Built-in IP management allows for remote camera reset, monitoring and reporting via various IP protocols.
eBridge4SK enables cost-effective system upgrades and eliminates the costs and labor associated with installing new network cabling.
Note: Ethernet maximum distance (see Maximum Length of Coax Type vs. Camera Power/PoE Class, pg. 3).
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
Input:
• eBridge100SPR - 51-56VDC/60W max. power.*
eBridge4SPT - powered by eBridge100SPR.
Power Output:
• eBridge4SPT: 4 ports PoE+ (30W) per port.
• Total output power: 60W.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair Cat-5e or better structured cable.
• Distance: up to 100m.
• Speed: 10/100BaseT, half/full duplex, auto negotiation.
Coax:
• Distance: up to 300m.
• Connectivity: BNC, RG-59/U or similar.
• Throughput is rated to pass 100mbps from camera to receiver.
With the proper headend equipment
multiple Megapixel cameras can be used.
LED Indicators:
• Blue LED - Coax link connection.
*UL Listed Class 2 or limited power source (NetWay1D).
eBridge4SK
Installation Guide
PLUS
Overview:
Features:
LED Indicators (cont'd):
• Green LED - Power (eBridge100SPR only).
• Yellow and Green LED (RJ45) IP Link status, 10/100Base-T/active.
Environmental:
• Operating Ambient Temperature :
eBridge100SPR:
eBridge4SPT: 60W: -40ºC to 75ºC (-40ºF to 167ºF).
• Storage Temperature: -40ºC to 75ºC (-40ºF to 167ºF).
• Humidity: 20 to 85%, non-condensing.
Applications:
• Retrofit digital IP cameras in an analog CCTV installation (up to four (4)
IP cameras expansion per analog camera).
• Works with Megapixel, HD720, HD1080 and VGA (SD) cameras
(see note, pg. 2).
• Extend Network link distance in an industrial environment.
• Upgrade deployed CCTV Coax to a digital network in Retail, Hospitality,
Arenas, Casinos, Airports, Schools, Hospitals, Transportation, etc.
Mechanical:
• Dimensions (H x W x D approx.):
eBridge100SPR: 4.375" x 3.5" x 1" (111.125mm x 88.89mm x 25.4mm)
eBridge4SPT: 1.7" x 5.23" x 8.93" (43.18mm x 132.84mm x 226.82mm)
-40ºC to 60ºC (-40ºF to 140ºF).
Rev. 072313
I.T.E. 43KC
- 1 -
Advertisement
Table of Contents
Related Manuals for Altronix eBridge100SPR
Summary of Contents for Altronix eBridge100SPR
-
Page 1: Installation Guide
10/100 Base-T Ethernet digital communication. eBridge4SPT allows you to upgrade your existing infrastructure by replacing a single analog device with up to four (4) PoE/PoE+ devices. eBridge100SPR passes data and sends power over the coax to the eBridge4SPT. Data transmission and power over the Coax are possible up to 300m. -
Page 2: Installation Instructions
UL Listed and/or Recognized wire suitable for the application. eBridge100SPR and eBridge4SPT is not intended to be connected to outside plant leads and should be installed indoors within the protected premises. The eBridge100SPR and eBridge4SPT is intended for indoor use only. -
Page 3: Typical Application
1. Set the static IP address for the laptop to be used for programming to the same network IP address as the eBridge4SPT, i.e. 192.168.168.200 (the default address of the eBridge4SPT is 192.168.168.168). 2. Connect one end of the network cable to the network jack on the eBridge100SPR and the other to the network connection of the laptop. eBridge4SK... -
Page 4: Network Setup
3. Open a browser on the computer and enter “192.168.168.168” into the address bar. A dialog box Authentication Required will appear requesting both user name and password enter the default values here. Click on the button labeled Log In. 4. The status page of the eBridge4SPT will appear. This page displays the real time status and health of each device connected to the eBridge4SPT. Network Setup: Click on the tab labeled Network Settings. - Page 5 Click OK. Email Settings (Fig. 2d, pg. 4): The eBridge4SPT can send emails via an in-house email server, email service provider (i.e. Gmail, Yahoo) or Altronix default email service. In-house email server: 1. From: Enter the email address assigned to the eBridge4SPT module by the system administrator.
- Page 6 network administrator and repeat the email setup sets. After all fields have been programed click the button labeled Reboot Server. A dialog box will display “Please allow up to 30 sec. for server to reboot”. Click OK. All programmed information will be saved after the server has rebooted. Setup: Click on the tab labeled Setup.
-
Page 7: Management Interface
Events Log eBridge4SPT Using a private SSL certificate and Key (Fig. 4b, pg. 7): Security Settings Private SSL Certificates and Keys must be uploaded using the Altronix Dashboard. Site ID: RJ Sports Wear Friday, Jul 31 2015 [9:10 am] Fig. 4b For additional information refer to the Altronix Dashboard setup/user manual section Updating firmware / SSL certificate and Key. -
Page 8: Events Log
Locality: Brooklyn SSL State: Turn SSL On Organization: RJ Sports Wear Inc. Change Username and Password (Fig. 4c, pg. 8): Fig. 4c Unit Name: eBridge4SPT 1. Username: Enter the new Username (up to 32 characters) required to access the eBridge4SPT. Change Username and Password: 2. -
Page 9: Updating Firmware
Heartbeat Timer Settings: Submit Days Hours Minutes Seconds Updating Firmware: Firmware updates must be done using the Altronix Dashboard. For additional information refer to the Altronix Dashboard setup/user manual’s section Updating firmware / SSL certificate and Key. eBridge4SK - 9 -... - Page 10 Status Screen: a. Class Power (Watts) (Fig. 7a, pg. 10): Wattage required by the PoE class of the device. b. Actual Power Draw (Watts) (Fig. 7b, pg. 10): Amount of watts being drawn by the connected device. c. Device Status (Fig. 7c, pg. 10): Active or Inactive. d.
- Page 11 Notes: eBridge4SK - 11 -...
-
Page 12: Shelf Installation
Four (4) rubber pads Rubber Feet Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. MEMBER IIeBridge4SK I25O - 12 -...
