- Page 1 Rittling Cabinet Convectors Installation, Operation and Maintenance Heating Cooling Fresh Air Clean Air...
-
Page 2: Table Of Contents
Models Ratings Dimensions and data General information Receiving Safety considerations Unpacking and preparation Handling and installation Hot water connections Exposed unit touch-up Heating system Water system balancing Water treatment Maintenance Equipment start-up checklist IMPORTANT: Submittal documentation, specific to Replacement parts each project, supersedes the general guidelines contained within this manual. -
Page 3: Models
Models Floor models FL: Floor, flat top SF: Floor, sloped top Wall models WL: Wall, flat top RL: Wall, semi-recessed SL: Wall, sloped top PL: Wall, fully recessed Models... -
Page 4: Ratings
Steam ratings Table 1: BTU/H (215 °F at 65 °F E.A.T.) Type SL slope top wall mounted nominal heights Type SF slope top free standing nominal heights Depth (in.) Length (in.) 3936 4056 4248 4416 3600 3744 4080 4248 4776... -
Page 5: Dimensions And Data
Dimensions and data Model FL Floor, flat top Standard dimensions Nominal heights (H) 18*, 20, 26, 32 Nominal lengths (L) 24, 28, 36, 40, 48, 52, 60, 64 Nominal depths (D) 4, 6, 8 Any combination of length, height and depth is available ■... - Page 6 Dimensions and data Model SF Floor, sloped top Standard dimensions Nominal heights (H) 18*, 20, 26, 32 Nominal lengths (L) 24, 28, 36, 40, 48, 52, 60, 64 Nominal depths (D) 4, 6, 8 Any combination of length, height and depth is available ■...
- Page 7 Dimensions and data Model WL Wall, flat top Standard dimensions Nominal heights (H) 18*, 20, 26, 32 Nominal lengths (L) 24, 28, 36, 40, 48, 52, 60, 64 Nominal depths (D) 4, 6, 8 Any combination of length, height and depth is available ■...
- Page 8 Dimensions and data Model RL Wall, semi-recessed Standard dimensions Nominal heights (H) 14*, 18*, 20, 24, 26, 32 Nominal lengths (L) 20, 24, 28, 32, 36, 40, 44, 48, 52, 56, 60, 64 Nominal depths (D) 4, 6, 8 Any combination of length, height and depth is available ■...
- Page 9 Dimensions and data Model SL Wall, sloped top Standard dimensions Nominal heights (H) 18*, 20, 26, 32 Nominal lengths (L) 24, 28, 36, 40, 48, 52, 60, 64 Nominal depths (D) 4, 6, 8 Any combination of length, height and depth is available ■...
- Page 10 Dimensions and data Model PL Wall, fully recessed Standard dimensions Nominal heights (H) 18*, 20, 26, 32 Nominal lengths (L) 24, 28, 36, 40, 48, 52, 60, 64 Nominal depths (D) 4, 6, 8 Recessed depths (R) 3-3/4, 5-3/4, 7-5/8 Any combination of length, height and depth is available ■...
-
Page 11: General Information
Receiving Upon delivery, examine the is begun. Zehnder Rittling is shipment against the bill of not responsible for any repairs lading to make sure all of the or alterations made by the... -
Page 12: Safety Considerations
Safety considerations The installation of Rittling All fastening devices must be The manufacturer assumes Cabinet Convectors and all designed to mechanically hold no responsibility for personal associated components, parts the assembly in place without injury or property damage and accessories which make the ability to loosen or break resulting from improper or unsafe up the installation, shall be in... -
Page 13: Unpacking And Preparation
Unpacking and preparation All units are carefully inspected Once the equipment is properly at the factory throughout the positioned on the job site, entire fabrication and assembly cover the units with either a processes under Zehnder shipping carton, vinyl film, or an Rittling’s stringent quality equivalent protective covering. -
Page 14: Handling And Installation
Although Zehnder Rittling blade during operation. does not become involved with the design and selection After mounting the unit, it is... -
Page 15: Hot Water Connections
Zehnder Rittling will not accept a gas, hydronic systems should any charges associated with be tested with water. Test re-insulating piping if the... -
Page 16: Exposed Unit Touch-Up
Exposed unit touch-up and repainting Units will be furnished with an After this preparation is finished, epoxy powder coated paint finish. the factory finish should provide Small scratches in the finish may excellent adhesion for a variety be repaired with touch-up spray of air dried top coats. -
Page 17: Water System Balancing
Water system balancing Water treatment A complete knowledge of the Proper water treatment is All Zehnder Rittling water coils hydronic system, including its a specialized industry and are constructed of copper tubes components and controls, is therefore it is recommended and brass headers. -
Page 18: Maintenance
Maintenance Before each heating season, For a deeper cleaning, spray remove front panel and inspect the finned surface with a mild coil fins for accumulation of dust alkali cleaning solution and rinse or other debris that may block thoroughly. airflow between fins. Brush the entire finned surface with a soft Failure to maintain a clean coil bristled brush, brushing parallel... -
Page 19: Replacement Parts
Replacement parts may including an RGA (Returned be purchased through the Goods Authorization) to be used local Zehnder Rittling Sales when sending components back Representative. for inspection. Any returned components sent back to the Contact the local Sales... - Page 20 Zehnder Rittling · 100 Rittling Boulevard · Buffalo, NY USA 14220 T 716-827-6510 · F 716-827-6523 · sales@zehnder-rittling.com · www.zehnder-rittling.com...
