- Page 1 Rittling Fanvector Installation, Operation and Maintenance Heating Cooling Fresh Air Clean Air...
-
Page 2: Table Of Contents
Arrangements General information Dimensions and data Installation Wiring diagram Operation Maintenance IMPORTANT: Submittal documentation, specific to Service parts each project, supersedes the general guidelines Warranty contained within this manual. -
Page 3: Arrangements
Free standing floor Floor an aesthetically pleasing solution for the architect. Recessed floor General data Table 1: General data Size FV-04 FV-06 FV-08 General Heating capacity (BTUH)* 8,900 13,900 19,600 Flow rate (GPM)* Operating pressure (psi) -
Page 4: Dimensions And Data
Dimensions and data Model FV-04 16-gauge powder coated finish enclosure Iso view 4-1/2" Electrical access door with 1/4 turn Louvered fastener 5" x 5" 8" outlet 4-25/32" Side view Less end panel Louvered inlet 2-7/8" R 3/16" 1-3/8" R 3/8"... - Page 5 Dimensions and data Model FV-06 16-gauge powder coated finish enclosure Iso view 4-1/2" Electrical access door with 1/4 turn 8" 4-25/32" Louvered fastener 5" x 5" outlet Side view Louvered inlet Less end panel 2-7/8" R 3/16" 1-3/8" R 3/8" Back view Mounting location 49-11/16"...
- Page 6 Dimensions and data Model FV-08 16-gauge powder coated finish enclosure Iso view 4-1/2" Electrical access 8" door with 1/4 turn 4-25/32" fastener 5" x 5" Louvered outlet 1/4-20 PPH Side view fastener Less end panel Louvered inlet 2-7/8" R 3/16" 1-3/8"...
- Page 7 Dimensions and data Recessed floor Iso view Recessed floor # of Model box length blowers FV-04-T 46" FV-06-T 64" Recessed floor box FV-08-T 82" Length is determined by number of blowers (see chart) Blower removable Debris screen to be for maintenance...
-
Page 8: Installation
Installation Inspection Upon receipt of the equipment, carefully check the shipment against the bill of lading. Make sure all units have been received. Inspect the packaging of each unit, and inspect each unit for damage. Ensure that the carrier makes proper notation of any shortages or damage on all copies of the freight bill and completes a common carrier inspection report. - Page 9 Proper wall supports and screws to support the Rittling Fanvector weight should be used when mounting. The table below shows model weights for each unit size. Model Weight (lbs.) FV-04 FV-06 FV-08 Access to the keyhole slots may require removal of the end panels ■...
- Page 10 Installation Plumbing The Rittling Fanvector is supplied with either opposite end, same end ■ ■ or recessed floor connections. Š Opposite end connections have brass headers with a 3/4" FPT connection. The headers have a 1/4" FPT hole that can be plugged or fitted with a vent (by others).
-
Page 11: Wiring Diagram
Thermostat shipped loose if wall mounted Size # of Blowers Control valve and changeover switch are shipped loose FV-04 Complete the wiring in accordance with national FV-06 and local codes FV-08 If remote temperature sensor is used, wire to thermostat tb1, terminals 1 and 2. -
Page 12: Operation
Operation Initial start-up Verify that all isolation valves are open and control valves (if any) are ■ ■ wired. Verify that all air has been removed from the hot water system and ■ ■ there is no air trapped in the coil. Verify that voltage is within an acceptable range and that fuses and ■... -
Page 13: Maintenance
Verify that the power is disconnected prior to cleaning. ■ ■ Cabinet Clean with a mild soap and warm water as necessary. ■ ■ Service parts Description FV-04 FV-06 FV-08 Same end 11723000005A 11723000006A 11723000007A connection coil Opposite end 11723000016A... -
Page 14: Warranty
Zehnder Rittling, the purchaser shall return the defective good(s) to the factory for inspection with freight prepaid. If inspection shows the goods to be defective, Zehnder Rittling will at its discretion repair or replace the said item(s). Defects arising from damage due to shipment, improper installation, negligence or misuse by others are not covered by this warranty. - Page 16 Zehnder Rittling · 100 Rittling Boulevard · Buffalo, NY USA 14220 T 716-827-6510 · F 716-827-6523 · sales@zehnder-rittling.com www.zehnder-rittling.com...
