Loshine wireless mouse
Art. no. 38-4356-1 -2 -3
Model G900A
Please read the entire instruction manual before use and save it for
future reference. We reserve the right for any errors in text or images
and for making any necessary technical changes to this document.
If you should have any questions concerning technical problems
please contact our Customer Services.
Description of the product
• Cordless laser mini-mouse (2.4 GHz).
• Two-button mouse with clickable scroll wheel.
• Suitable for use with a laptop.
• DPI setting (800/1200/1600 DPI).
• Range up to 10 m.
• Battery supplied.
• Micro USB receiver for USB port, stored under the mouse.
• Compatible with XP/Vista/Win 7.
System requirements
• USB port
• Windows XP/Vista/Win 7
The package contains
• Cordless mini-mouse
• Receiver with USB plug (stored under the mouse)
• Battery: one AAA/LR03
• User guide
Care and maintenance
Wipe the product with a damp cloth. Never use cleaning agents or
strong solvents.
Installation
1. Push the battery cover latch on
2. Install the battery,
the underside to the side and open
observing the markings
the battery compartment.
in the battery compart-
ment. Close the battery
cover.
P C
3. Switch on the mouse with the
4. Connect the micro-
switch. A blue LED flashes on top
receiver to a free
of the mouse.
USB port on your
computer.
5. The mouse is now ready to use.
GREAT BRITAIN • for consumer contact, please visit www.clasohlson.co.uk and click on customer service.
SVERIGE • kundtjänst tel. 0247/445 00, fax 0247/445 09, e-post kundtjanst@clasohlson.se, internet www.clasohlson.se
NORGE • kundesenter tel. 23 21 40 00, fax 23 21 40 80, e-post kundesenter@clasohlson.no, internett www.clasohlson.no
SUOMI • asiakaspalvelu puh. 020 111 2222, sähköposti info@clasohlson.fi, kotisivu www.clasohlson.fi
Functions
P C
A red LED flashes when
The receiver is stored
the battery is low.
on the underside of
the mouse.
Power switch. Save
The sensitivity of the mouse can be set
power by switching off
between 800 and 1600 DPI. Use the button
the mouse when it is
on the underside of the mouse to change
not in use. The battery
the sensitivity. The factory setting is 800 DPI.
indicator flashes when
• At 800 DPI the blue LED flashes once.
the mouse is switched
• At 1200 DPI the blue LED flashes twice.
off.
• At 1600 DPI the blue LED flashes
three times.
Disposal
Follow local ordinances when disposing of this product. If you are
unsure about how to dispose of this product contact your local
authority.
Specifications
Frequency range
2.4000–2.4835 GHz
Range
Up to 10 metres
Power supply
1.5 V battery (one AAA/LR03)
Type
Laser
Resolution
800/1200/1600 DPI
USB interface
1.1
Dimensions
80 x 55 mm
Points worth bearing in mind!
• Other wireless equipment operating on the same frequency
band may reduce the range of the product.
• The range of all wireless equipment is affected by obstacles
between the transmitter and the receiver (a concrete wall
reduces the signal far more than a plasterboard partition,
for example).
If you are having problems with the operation
of the system, try the following solutions
• Switch off any other wireless equipment to check whether it
could be causing the problem.
• Move the wireless equipment and/or reduce the distance, and
reduce the number of obstacles (walls, furniture, etc.) between
the transmitter and the receiver.
Trådlös mus Loshine
Art.nr 38-4356-1 -2 -3
Modell G900A
Läs igenom hela bruksanvisningen före användning och spara den
sedan för framtida bruk. Vi reserverar oss för ev. text- och bildfel
samt ändringar av tekniska data. Vid tekniska problem eller andra
frågor, kontakta vår kundtjänst.
Produktbeskrivning
• Trådlös minimus laser (2,4 GHz).
• 2-knappars med klickbart scrollhjul.
P C
• Lämplig för användning med laptop.
• DPI-inställning (800/1200/1600 DPI).
• Räckvidd upp till 10 m.
• Batteri medföljer.
• USB-mottagare i mikroformat för USB-port som förvaras
i musens undersida.
• Passar XP/Vista/Win 7.
Systemkrav
• USB-anslutning
• Windows XP/Vista/Win 7
Förpackningen innehåller
• Trådlös minimus
• Mottagare med USB-anslutning (förvaras på undersidan av musen)
• 1 x AAA/LR03-batteri
• Bruksanvisning
Skötsel och underhåll
Torka av produkten med en lätt fuktad trasa. Använd aldrig
rengöringsmedel eller starka lösningsmedel.
Installation
1. Tryck batteri-luckans spärr på
2. Sätt i batteriet
undersidan åt sidan och öppna
enligt märkningen i
batteriluckan.
batterifacket. Sätt
tillbaka batteriluckan.
P C
3. Starta musen med strömbrytaren.
4. Anslut mikromottaga ren
En blå lysdiod blinkar på ovan sidan
till en ledig USB-port
av musen.
på din dator.
5. Musen är nu redo att användas.
Funktioner
P C
En röd lysdiod blinkar
Mottagaren förvaras
när bat teriet är svagt.
på undersidan av
musen.
Strömbrytare: Spara
Det går att ändra musens känslighet mel-
ström genom att stänga
lan 800–1600 DPI. Använd knappen på
av musen när den inte
undersidan av musen till att ändra känslig-
används. Indikatorn
heten. Fabriksinställningen är 800 DPI.
för batteri blinkar när
• Vid 800 DPI blinkar den blå lysdioden
musen stängs av.
en gång.
• Vid 1200 DPI blinkar den blå lysdioden
två gånger.
• Vid 1600 DPI blinkar den blå lysdioden
tre gånger.
Avfallshantering
När du ska göra dig av med produkten ska detta ske enligt lokala före-
skrifter. Ar du osäker på hur du ska gå tillväga, kontakta din kommun.
Specifikationer
Frekvensområde
2.4000 - 2.4835 GHz
Upp till 10 meter
Räckvidd
Strömförsörjning
1,5 V batteri (1 x AAA/LR03)
Typ
Laser
Upplösning
800/1200/1600 DPI
USB Interface
1.1
Mått
80 x 55 mm
Tänk på
• Att annan befintlig trådlös utrustning på samma frekvensband kan
påverka räckvidden negativt.
• Att räckvidden på all trådlös utrustning påverkas av vilka
hinder som finns mellan sändaren och mottagaren (t.ex. en
betongvägg dämpar signalen avsevärt mer än en gipsvägg).
Vid funktionsproblem, prova följande lösningar
• Stäng av övriga befintliga trådlösa utrustningar för att kontrollera
om de kan vara orsaken till problemet.
• Flytta den trådlösa utrustningen och/eller förkorta avståndet, samt
minska antalet hinder (väggar, möbler etc.) mellan sändaren och
mottagaren.
