11/14/2001
1. Filter Vent
2. Filter Vent Seal
3. Filter Collar
4. Filter Cover
Emergency Starting With
Jumper Cables
When using jumper cables, follow the instructions
below.
WARNING
Batteries release explosive gas. Do not smoke
when working around batteries. Put out all flames
and remove all sources of sparks or intense heat
1
2
3
4
5
6
7
5. Filter Cover Seal
6. Spring
7. Filter Element
Fig. 13.2, Davco Model 232 and 233 Fuel/Water Separator
In an Emergency
8
10
8. Threaded Stud
9. Fuel Port
10. Drain
in the vicinity of the battery. Do not allow the ve-
hicles to touch each other. Do not lean over the
batteries when making connections, and keep all
other persons away from the batteries. Failure to
follow these precautions could lead to severe
personal injury as a result of an explosion or
acid burns.
9
f470416
13.2
