Infinity "M" Surface Mount System (Shown With Optional Cctv) - Sentex Infinity Design Manual

C. INFINITY "M" SURFACE MOUNT SYSTEM (SHOWN WITH OPTIONAL CCTV)
Display
1564F1
This line drawing is intended for dimensional reference purposes only and is not intended to be an actual
drawing of the Infinity "M" system itself. NOTE: Camera is optional.
Page 8 of 19
11 3/4"
2 X 20
LCD
Keypad
Camera
1
4 5 6
7
Enclosure
Lock
Postal
Speaker
FRONT VIEW
16.0"
Micro-
2 3
phone
9
8
0 #
Lock
Doc 6001564
3/4"
3 1/2"
4 1/4"
SIDE VIEW
Rev B
