E. INFINITY "S" SURFACE MOUNT SYSTEM
1114F7
This line drawing is intended for dimensional reference purposes only and is not intended to be an actual
drawing of the Infinity "S" system itself.
Page 10 of 19
11 3/4"
Small
LCD
Display
Enclosure
Lock
Speaker
FRONT PANEL
Doc 6001564
Keypad
16.0"
Micro-
1 2 3
phone
4 5 6
7 8 9
0 #
Postal
Lock
3/4"
2 1/2"
3 1/4"
SIDE VIEW
Rev B
