Summary of Contents for Sentex Infinity
- Page 1 Rev B Rev B Rev B DESIGN GUIDE DESIGN GUIDE DESIGN GUIDE DESIGN GUIDE INFINITY SYSTEMS INFINITY SYSTEMS INFINITY SYSTEMS INFINITY SYSTEMS WITH STAND ALONE OR MULTI WITH STAND ALONE OR MULTI WITH STAND ALONE OR MULTI WITH STAND ALONE OR MULTI- - - - LINK FIRMWARE...
-
Page 2: Table Of Contents
The purpose of this guide is to assist you in meeting any specification requirements you may encounter in installing an Infinity system. The information enclosed in this manual is to be used for reference purposes only and is not intended to be an installation or programming manual. -
Page 3: Cabinet Dimensions
1. CABINET DIMENSIONS TYPE OF SYSTEM HEIGHT WIDTH DEPTH Infinity “L” or “DI” Surface Mount 21.0” 16 7/16” 4 1/4” Flush Mount Back Box 21 1/4” 16 3/4” 3 3/16” Flush Mount Bezel 23 11/16” 19 3/16” Infinity “M” Surface Mount 16.0”... -
Page 4: Cabling To The Telephone Inter Face Board
Shielded-Belden #9929 “TB2” on the second unit (50 ft. max.) 18 to 24 awg cable Unshielded-Belden #8445 E. CABLING FOR ADDITIONAL FEATURES On an Infinity System Type of Wire Recommendations From a computer terminal 3 conductor Use shielded cable only to the Main Processor Board (50 ft. -
Page 5: Cabling For Factory-Supplied Video Camera Option
On a Multi-Link System (Continued) Type of Wire Recommendations Between an External Telephone Modem 3 conductor Use shielded cable only and the first unit of the system (50 ft. max.) 18 to 24 awg cable Shielded-Belden #9925 Between an External Telephone Modem 2 conductor, Use unshielded cable only and a Stand-Alone Short-Haul Modem (50 ft. -
Page 6: Dimensional Drawings Of Infinity
3. DIMENSIONAL DRAWINGS OF INFINITY A. INFINITY “ L” SURFACE MOUNT SYSTEM (SHOWN WITH OPTIONAL CCTV) This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “L” system itself. NOTE: Camera is optional. -
Page 7: Infinity "L" Flush Mount System
B. INFINITY “L” FLUSH MOUNT SYSTEM FLUSH MOUNT BOX This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “L” Flush Mount system itself. Rev B Doc 6001564... -
Page 8: Infinity "M" Surface Mount System (Shown With Optional Cctv)
SIDE VIEW 1564F1 This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “M” system itself. NOTE: Camera is optional. Page 8 of 19 Doc 6001564 Rev B... -
Page 9: Infinity "M" With Camera Flush Mount System
REAR VIEW 1564F2 FLUSH MOUNT BOX This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “M” Flush Mount system itself. Rev B Doc 6001564 Page 9 of 19... -
Page 10: Infinity "S" Surface Mount System (Shown With Optional Cctv)
3 1/4" SIDE VIEW FRONT PANEL 1114F7 This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “S” system itself. Page 10 of 19 Doc 6001564 Rev B... -
Page 11: Infinity "S" Flush Mount System
F. INFINITY “S” FLUSH MOUNT SYSTEM FLUSH MOUNT BOX This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “S” Flush Mount system itself. Rev B Doc 6001564... -
Page 12: Infinity "Di"Surface Mount System
G. INFINITY “DI” SURFACE MOUNT SYSTEM This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “DI” system itself. Page 12 of 19 Doc 6001564 Rev B... -
Page 13: Infinity "Di" Flush Mount System
H. INFINITY “DI” FLUSH MOUNT SYSTEM FLUSH MOUNT BOX This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “DI” Flush Mount system itself. Rev B Doc 6001564... -
Page 14: Infinity "B" System
I. INFINITY “B” SYSTEM This line drawing is intended for dimensional reference purposes only and is not intended to be an actual drawing of the Infinity “B” system itself. Page 14 of 19 Doc 6001564 Rev B... -
Page 15: Camera Mounting
J. CAMERA MOUNTING Side View This drawing is provided for your information only. Rev B Doc 6001564 Page 15 of 19... -
Page 16: Illustration Of Processor Boards
4. ILLUSTRATION OF PROCESSOR BOARDS A. 1100072 MAIN PROCESSOR BOARD (REVISION “H”) KEYPAD LIGHT HEATER A MONTIOR CLEAR 12V AC/ J19 J18 13.5V DC FAN B FAN A POWER GROUND SCREW CLEAR TO SEND RS232 OUT RS232 GROUND PORT 1 RS232 IN REQUEST TO SEND... -
Page 17: 1100329 Model Telephone Interface Board
B. 1100329 MODEL TELEPHONE INTERFACE BOARD Telephone Interface Board (SN1100329) LINE RING OFF HOOK HANDSET CLICK LEVEL PANEL SPEAKER CLICK LEVEL SPEAKER LEVEL CLICK DETECT Daughter Board (SN1110080) LINE BAL 1 LINE BAL 2 TELCO LINE PANEL SENS GROUND 1564F3 Rev B Doc 6001564 Page 17 of 19... -
Page 18: Auxiliary Relay Module Board
C. AUXILIARY RELAY MODULE BOARD Page 18 of 19 Doc 6001564 Rev B... -
Page 19: 1110076 Power Supply Board
D. 1110076 POWER SUPPLY BOARD WITH BOARD MOUNT CAMERA IMPORTANT NOTE: Do not use the same power supply for this board as for the telephone entry system. The power inputs must be isolated. Rev B Doc 6001564 Page 19 of 19...
