B. CABLING TO THE TELEPHONE INTER FACE BOARD
Cabling to the Telephone Interface Board
From the telephone company jack
C. CABLING BETWEEN UNITS WITH DUAL SHORT HAUL MODEMS
(Multi-Link Systems only)
From "LINE 2" on the first unit and
"LINE 1" on the second unit (5000 ft. max.)
D. CABLING BETWEEN UNITS WITHOUT DUAL SHORT-HAUL MODEMS
(Multi-Link Systems only)
From "TB3" on the first unit and
"TB2" on the second unit (50 ft. max.)
E. CABLING FOR ADDITIONAL FEATURES
On an Infinity System
From a computer terminal
to the Main Processor Board (50 ft. max.)
From a printer
to the Main Processor Board (50 ft. max.)
From a Stand-Alone Modem
to the Main Processor Board (50 ft. max.)
From a Remote Keypad
to the Main Processor Board (500 ft. max.)
From a Wiegand, Barium Ferrite, Proximity,
or Clikcard card reader to the
Main Processor Board (500 ft. max.)
On a Multi-Link System
Between a Computer Terminal
and the first unit of the system (50 ft. max.)
Between A Computer Terminal
and a Stand-Alone Short Haul Modem (50 ft. max.)
Between a Printer and the
first (or last) unit of the system (50 ft. max.)
Between a Printer and a
Stand-Alone Short-Haul Modem (50 ft. max.)
Between a Printer and
the AUX port of a terminal (50 ft. max.)
Page 4 of 19
Type of Wire
2 conductor,
18 to 22 awg cable
Type of Wire
2 conductor, 16 to 24 awg
twisted pair cable
Type of Wire
5 conductor,
18 to 24 awg cable
Type of Wire
3 conductor
16 to 24 awg cable
3 conductor
16 to 24 awg cable
3 conductor
18 to 24 awg cable
7 conductor
20 to 24 awg cable
5 conductor
24 awg cable
Type of Wire
3 conductor
18 to 24 awg cable
2 conductor,
16 to 24 awg,
twisted pair cable
3 conductor
18 to 24 awg cable
2 conductor,
16 to 24 awg,
twisted pair cable
2 conductor
18 to 24 awg cable
Doc 6001564
Recommendations
Shielded-Belden #9501
Unshielded-Belden #8740
Recommendations
Shielded-Belden #9501
Unshielded-Belden #8740
Recommendations
Shielded-Belden #9929
Unshielded-Belden #8445
Recommendations
Use shielded cable only
Shielded-Belden #9925
Use shielded cable only
Shielded-Belden #9925
Use shielded cable only
Shielded-Belden #9925
Use shielded cable only
Shielded-Belden #9932
Use shielded cable only
Shielded-Belden #9929
Recommendations
Use shielded cable only
Shielded-Belden #9925
Use unshielded cable only
Unshielded-Belden #8740
Use shielded cable only
Shielded-Belden #9925
Use unshielded cable only
Unshielded-Belden #8740
Use shielded cable only
Shielded-Belden #9501
Rev B
