CSX IRS10
10 Channel Infrared Systen

USER MANUAL

CSX IRS10 Manual V1.1
1 / 32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSX IRS10 and is the answer not in the manual?

Questions and answers

Related Manuals for AKG CSX IRS10

Summary of Contents for AKG CSX IRS10

  • Page 1: User Manual

    CSX IRS10 10 Channel Infrared Systen USER MANUAL CSX IRS10 Manual V1.1 1 / 32...

  • Page 2: Table Of Contents

    Please read before using the equipment! Printed in Hungary January 2015 Version: 1.1 Contents CONTENT 1. GENERAL INFORMATION ....................5 1.1. I ....................... 5 NTRODUCTION 2. CSX IRS10 SYSTEM SERVICES ..................5 2.1. C ......................5 ORE FUNCTIONS 2.2. G ..................6 ENERAL YSTEM HARACTERISTICS 2.3.

  • Page 3: Safety Instructions

    If any solid object or liquid penetrates into the equipment, shut down the system immediately. Disconnect the equipment from power immediately and have the equipment checked by AKG service personnel. If you will not use the equipment for a long period of time, disconnect the equipment from power.
  • Page 4 Use the equipment for the applications described in this manual only. AKG cannot accept any liability for damage resulting from improper handling or misuse. Any changes or modifications to the equipment not expressly approved by the manufacturer may void the user's authority to operate the equipment.

  • Page 5: General Information

    2.1. C ORE FUNCTIONS The basic components of the CSX IRS10 system of the conference contain a CSX BIR10 controller, CSX IRT3, CSX IRT4 IR radiators, a number of CSX IRR10 pocket receivers and the CS5 PS12 - 48V power supply. When using the system in the CS5 conference loop you can take up to 10 language channels from the system bus, which can then be recorded or distributed from the RCA socket of BIR10.

  • Page 6: General System Characteristics

    All used system cables (between IRS10 units) have to be shorter then 3m, except 50 ohm coax from BIR10 to IRT3-4. This point to point length can be up to 100m as maximum. CSX IRS10 Manual V1.1 6 / 32...
  • Page 7 Diagram 1: Overview drawing of system IRS 10. IRT3, IRT4 transmitters IRR10 channel receiver INPUT1-10: Analog 0dBU external sources OUTPUT1-10: Analog 0dBU channels 48V DC power from Cs5 system bus CS5 conference system with BU controller CS5 conference ring CSX IRS10 Manual V1.1 7 / 32...

  • Page 8: Central Unit Bir 10

    ENTRAL UNIT 2.3.1. General introduction Central unit CSX BIR 10 is the core element of system CSX IRS10 and is required for all possible configurations. 2 modes are possible: 1. As part of CS5 system – in this mode the unit acts as 10 channel infrared modulator...

  • Page 9: Operation Guide

    RCA to use CS5 channels and feeding external sources to the input RCA board as well. That way you can fine tune all input levels using the input potis next to the input RCA, or using the right DIP switch configuration described further down. CSX IRS10 Manual V1.1 9 / 32...

  • Page 10: Dip Switches

    54-63 select audio source DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8 for the IR modulator ring/FPGA (according to DIP 1) Analog audio from backplane CSX IRS10 Manual V1.1 10 / 32...
  • Page 11 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8 Routing from CS 5 ring channel # 1-5 from ext. input # 10-14 11-15 20-24 21-25 30-34 31-35 40-44 41-45 50-54 51-55 59-63 CSX IRS10 Manual V1.1 11 / 32...
  • Page 12 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8 Routing from CS 5 ring channel # 10 from ext. input # 10-18 11-19 20-28 21-29 30-38 31-39 40-48 41-49 50-58 51-59 55-63 CSX IRS10 Manual V1.1 12 / 32...
  • Page 13 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8 Routing from CS 5 ring channel # 1-8 from ext. input # 10-11 11-12 20-21 21-22 30-31 31-32 40-41 41-42 50-51 51-52 60-61 61-62 CSX IRS10 Manual V1.1 13 / 32...

  • Page 14: Technical Data Csx Bir10

    CS5 compatible Audio input connectors INPUT 1 – INPUT 10 level INPUT impedance kOhm Audio output connectors OUTPUT 1 - OUTPUT 10 level Load impedance for outputs kOhm Relation of signal-noise at the outputs CSX IRS10 Manual V1.1 14 / 32...

  • Page 15: Connectors

    RJ 45 socket: Function Transmit Data + Transmit Data - Receive Data+ DC 48 V DC 48 V Receive Data - Coaxial cable connector: INFRA OUT BNC (50 ohm): Function PPM data signal CSX IRS10 Manual V1.1 15 / 32...

  • Page 16: Infrared Radiators Csx Irt 3 And Irt 4

    The layout of the indicating and connecting devices of the infrared radiators is shown on Diagram 1. CSX IRS10 Manual V1.1 16 / 32...
  • Page 17 „POWER” green LED - indicates the existence of the power „OPERATE” red LED - indicates the control signal existence at the INPUT „IN” - input coaxial connector (BNC) „OUT” - output coaxial connector (BNC) CSX IRS10 Manual V1.1 17 / 32...

  • Page 18: Technical Data: Irt3(Spot: +/-17°)

    870 nm Radiated power 12,5 W Angle of half intensity +/-17° Effective distance 65 m Power consumption (AC) 100 watts Switch ON transient Max: 2,5 A LED Status Green Power Supply Control Signal CSX IRS10 Manual V1.1 18 / 32...

  • Page 19: Technical Data: Irt4(Wide Range: +/-60°)

    870 nm Radiated power 11,4 watts Angle of half intensity +/-60° Effective distance 35 m Power consumption (AC) 100 watts Switch ON transient Max: 2,5 A LED States Green Power Supply Control Signal CSX IRS10 Manual V1.1 19 / 32...
  • Page 20 +-17 +-60 Radiated charasteristics and effective distances IRT3, IRT4 CSX IRS10 Manual V1.1 20 / 32...

  • Page 21: Irr10

    (DO NOT USE MONO PLUGS!) NAVY button for volume UP/DOWN and MUTE NAVY button for channel selection UP DOWN and push to ON/OFF USB socket for charging (to be used with CSX CU50 only) CSX IRS10 Manual V1.1 21 / 32...
  • Page 22 Diagram 7 CSX IRS10 Manual V1.1 22 / 32...
  • Page 23 (diagram 6 - 3). The volume can be set to the adequate level with the aid of the volume regulator diagram (6 - 2). In case of lacking radiation signal the device is muted (diagram 8 - 8). Diagram 8 CSX IRS10 Manual V1.1 23 / 32...

  • Page 24: Menu System Screens Of Irr10: (Diagram 8.)

    Name Switching off screen Volume Active (hearing) channel Battery status AKG logo (after ON, displaying for a short time) No IR signal Muted headphones out Full charged accu (at the end of the charging process) Running charging process (in the charging slot) Powering is ensured by 2x1, 4V-2000mAh NiMH (or 2x 1,5V AA battery).

  • Page 25: Service Menu And Channel - Mnemonic Settings

    See bellow how to enter the service menu of IRR10: STEP 1: Push and release the ON/OFF button and STEP 2: Push the VOLUME button while AKG logo can be seen and wait for the main menu. Then release the button. Service menu will be displayed.
  • Page 26 STEP1 STEP2 WARNING: Use only 3,5mm STEREO Jack for headphone connection. A mono JACK creates short circuit, resulting in bad sound and battery discharging. CSX IRS10 Manual V1.1 26 / 32...

  • Page 27: Technical Data

    Supply current “ON” 200 mA max. Output: +3dBu on 32 ohm load Supply current „OFF” 0 mA Auto switch off voltage 1,6V Battery status indication Linear (on display) Number of channels Receiver view angle 140° CSX IRS10 Manual V1.1 27 / 32...
  • Page 28 Total harmonic distortion at 1kHz <0,36 % Output power on 32 ohm load with 48 mW nominal input level (CSX BIR10 0dBU) Load impedance 32 Ohm ≥ Working/charging Working time Accu. charging time max: CSX IRS10 Manual V1.1 28 / 32...

  • Page 29: Charging - Storing Case Csx Cu50

    The overview drawing of the charging and storing case and the distribution of its operating and connecting devices are shown on Diagram 9. Diagram 9 – Overview drawing of charging-storing case CU 50 CSX IRS10 Manual V1.1 29 / 32...

  • Page 30: Technical Data

    STANDARD/MAINTANCE (constant/pulsed current) Charging parameters Charging mode STANDARD Maintenance Current/slot (5V) 540 mA 5 % 540 mA 5 % (pulsed) Continues Pulsed Technique current current dV/dt Termination methods max. time max. voltage max. voltage CSX IRS10 Manual V1.1 30 / 32...

  • Page 31: Placing, Cabling And Setting Up The Units Of The System

    Important! When connecting the radiators, the cable arriving from the central unit should be always connected to input marked „IN”, while the cable going to the next radiator should start from the output marked „OUT”. CSX IRS10 Manual V1.1 31 / 32...

  • Page 32: Co-Operation With Cs5 Conference System

    Laxenburgerstrasse 254, A-1230 Vienna/AUSTRIA, phone: (+43-1) 86654-0* e-mail: sales@akg.com For other products and distributors worldwide visit www.akg.com Technische Änderungen vorbehalten. Specifications subject to change without notice. Ces caractéristiques sont susceptibles de modifications. Ci riserviamo il diritto di effettuare modifiche tecniche. Nos reservamos el derecho de introducir modificaciones técnicas.
