- Page 1 GMSS400W MITER SAW STAND SUPPORT POUR SCIE À ONGLETS BASE PARA SIERRA INGLETADORA Operator’s Manual Manuel d’utilisation Manual del Operario TOLL FREE 888-552-8665 HELP LINE: www.genesispowertools.com WEBSITE:...
- Page 2 FIG 1 FIG 2...
- Page 3 FIG 3 FIG 5 FIG 4...
- Page 4 FIG 7 FIG 6 FIG 8 FIG 9 FIG 11 FIG 10 FIG 12...
-
Page 5: Specifications
Make sure all moving parts are free from interference. • Check to make sure that all securing screws and knobs are tight before using GMSS400W miter saw stand. • Make sure the Miter Saw Stand GMSS400W is set up on firm, level ground in a stable manner. -
Page 6: Contents In Package
• Never stand on the product. The total weight of the saw and the workpiece must not exceed 400 lb. • This stand will accommodate the miter saws with blade diameter of 12" or less. Never to be used with any miter saws with a blade diameter larger than 12". • Only use the GMSS400W for the purpose described in this manual. Any use other than those mentioned in this manual will be considered misuse. The manufacturer shall not be liable for any damage or injury resulting form such cases of misuse. SAVE THESE INSTRUCTIONS... - Page 7 If the saw has four holes that line up with the slots in the saw mounting brackets: 1. Unplug the miter saw and lock the saw head in the down position. 2. Lift one side of the saw and place a saw mounting bracket underneath it. Insert the mounting bolts provided through the slot in the bracket and through the miter saw mounting holes, as shown in FIG 6. NOTE: Use M6x35mm fastener set for Genesis™ GMS15LB and GMSUDR15L miter saws. Use M8x55mm fastener set for other Genesis™ miter saws. 3. Secure in place using a flat washer, lock washer and nut, in that order. 4. Repeat the steps 2 & 3 to install the second bracket to the other side of the miter saw. 5. Check that the brackets are parallel to each other, then hand tighten all four nuts to hold the saw in position.
-
Page 8: Operation
Choose a level area to set up the stand and adjust the adjustable foot so that all four legs are touching the ground. OPERATION USING THE EXTENSION RAILS (See FIG 10) Use the extension rails (2) when working with larger workpieces. To Extend the Rails 1. Loosen the extension locking knob (6). 2. Extend the rail (2) to the desired position. 3. Tighten the extension locking knob. Miter Saw Stand Operator’s Manual GMSS400W... -
Page 9: Maintenance
Chemicals can damage, weaken or destroy plastic which may result in serious personal injury. TWO-YEAR WARRANTY This product is warranted free from defects in material and workmanship for 2 years after date of purchase. This limited warranty does not cover normal wear and tear or damage from neglect or accident. The original purchaser is covered by this warranty and it is not transferable. Prior to returning your tool to store location of purchase, please call Toll-Free Help Line for possible solutions. TOLL-FREE HELP LINE 888-552-8665 For questions about this or any other GENESIS™ Product, please call Toll-Free: www.genesispowertools.com Or visit our web site: ©Richpower Industries, Inc. All Rights Reserved Richpower Industries, Inc. 736 Hampton Road Williamston, SC 29697 Printed in China, on recycled paper... - Page 12 Richpower Industries, Inc. 736 Hampton Road Williamston, SC USA www.richpowerinc.com 2012.12.05 V.01...
