Attaching / Removing the Base
Install:
Align the four hooks on the bottom of
the monitor with the corresponding
slots on the bottom of the base.

SCREEN POSITION ADJUSTMENT

In oder to optimize the best viewing position, you can adjust the tilt of the monitor by
using both of your hands to hold the edges of the monitor as shown in the figure below.
The monitor can be adjusted to 15 degrees up or 5 degrees down as indicated by arrow
below.
Remove:
Depress the four hooks as indicated first
before removing the base and follow the
arrow direction to remove it.
EN-4
AL1516W
