  • Page 1 B85M-VIEW PAKER...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... iv About this guide ......................iv Package contents ....................... vi B85M-VIEW PAKER specifications summary ............vi Product introduction Before you proceed ..................1-1 Motherboard overview ................. 1-2 Central Processing Unit (CPU) ..............1-4 System memory ................... 1-7 Expansion slots ..................

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: Conventions Used In This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Package Contents

    DDR3 1600MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600MHz. *** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). Graphics Integrated graphics processor - Intel HD Graphics support ®...
  • Page 7 1 x 4-pin ATX 12V power connector 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS BIOS features 2.7, ACPI 4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions Manageability WfM 2.0, DMI 2.0, WOL by PME, PXE...
  • Page 8 viii...

  • Page 9: Product Introduction

    • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS B85M-VIEW PAKER...

  • Page 10: Motherboard Overview

    1.2.2 Screw holes Place four screws into the holes indicated by circles to secure the motherboard to the chassis. Do not overtighten the screws! Doing so can damage the motherboard. Place this side B85M-VIEW PAKER towards the rear of the chassis Chapter 1: Product introduction...

  • Page 11: Motherboard Layout

    1-17 5. DDR3 DIMM slots 6. Intel B85 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~2) 1-17 ® 7. Intel B85 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~2) 1-18 ® 8. System panel connector (10-1 pin F_PANEL) 1-21 9. Speaker connector (4-pin SPEAKER) 1-16 10. Clear RTC RAM (2-pin CLRTC) 1-12 11. Chassis intrusion connector (4-1 pin CHASSIS) 1-20 12. mSATA/mPCIe slot (MSATA_MPCIE) 1-20 13. Front panel audio connector (10-1 pin AAFP) 1-16 14. USB 2.0 connector (10-1 pin USB1314) 1-19 15. USB 3.0 connector (20-1 pin USB3_12) 1-18 ASUS B85M-VIEW PAKER...

  • Page 12: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) This motherboard comes with a surface mount LGA1150 socket designed for the 4th Generation Intel Core™ i7 / Core™ i5 / Core™ i3, Pentium , and Celeron processors. ® ® ® B85M-VIEW PAKER B85M-VIEW PAKER CPU socket LGA1150 Unplug all power cables before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1150 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. 1.3.1 Installing the CPU Chapter 1: Product introduction...
  • Page 13 ASUS B85M-VIEW PAKER...

  • Page 14: Cpu Heatsink And Fan Assembly Installation

    1.3.2 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 1: Product introduction...

  • Page 15: System Memory

    To uninstall the CPU heatsink and fan assembly System memory 1.4.1 Overview This motherboard comes with two Double Data Rate 3 (DDR3) Dual Inline Memory Module (DIMM) sockets. A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for better performance with less power consumption. The figure illustrates the location of the DDR3 DIMM sockets: Channel Sockets Channel A DIMM_A1 B85M-VIEW PAKER Channel B DIMM_B1 B85M-VIEW PAKER 240-pin DDR3 DIMM sockets ASUS B85M-VIEW PAKER...

  • Page 16: Memory Configurations

    OS if you want to install 4GB or more on the ® motherboard. F or more details, refer to the Microsoft support site at http://support.microsoft. ® com/kb/929605/en-us. • This motherboard does not support DIMMs made up of 512 megabits (Mb) chips or less. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. To operate at the vendor-marked or at a higher frequency, refer to section 2.5 Ai Tweaker menu for manual memory frequency adjustment. • For system stability, use a more efficient memory cooling system to support a full memory load (2 DIMMs) or overclocking condition. • Visit the ASUS website at: www.asus.com for the latest QVL. Chapter 1: Product introduction...
  • Page 17 1.4.3 Installing a DIMM To remove a DIMM ASUS B85M-VIEW PAKER...

  • Page 18: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. 1.5.1 Installing an expansion card To install an expansion card: Before installing the expansion card, read the documentation that came with it and make the necessary hardware settings for the card. Remove the system unit cover (if your motherboard is already installed in a chassis).

  • Page 19: Irq Assignments For This Motherboard

    SATA controller – – – shared – – – – PCIE X16_1 shared – – – – – – – PCIE X16_2 – shared – – – – – – RTL8111GR shared – – – – – – – ASUS B85M-VIEW PAKER 1-11...

  • Page 20: Headers

    Clear RTC RAM (2-pin CLRTC) This header allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. B85M-VIEW PAKER CLRTC PIN 1 B85M-VIEW PAKER Clear RTC RAM To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Use a metal object such as a screwdriver to short the two pins. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. • If the steps above do not help, remove the onboard battery and short the two pins again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the...

  • Page 21: Connectors

    1Gbps connection (Blinking) Orange Ready to (Blinking then wake up from steady) S5 mode LAN port Line In port (light blue). This port connects to the tape, CD, DVD player, or other audio sources. Line Out port (lime). This port connects to a headphone or a speaker. In the 4.1, 5.1 and 7.1-channel configurations, the function of this port becomes Front Speaker Out. Microphone port (pink). This port connects to a microphone. Refer to the audio configuration table for the function of the audio ports in 2.1, 4.1, 5.1, or 7.1-channel configuration. ASUS B85M-VIEW PAKER 1-13...
  • Page 22 Audio 2.1, 4.1, 5.1, or 7.1-channel configuration Headset Port 4.1-channel 5.1-channel 7.1-channel 2.1-channel Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center Lime (Front panel) Side Speaker Out To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. USB 2.0 ports. These two 4-pin Universal Serial Bus (USB) ports are for USB 2.0/1.1 devices.

  • Page 23: Internal Connectors

    Power OK -5 Volts PIN 1 +5 Volts +5 Volts PSON# +3 Volts -12 Volts +3 Volts +3 Volts PIN 1 B85M-VIEW PAKER ATX power connectors • We recommend that you use an ATX 12V Specification 2.0-compliant power supply unit (PSU) with a minimum of 300W power rating. This PSU type has 24-pin and 4-pin power plugs. • DO NOT forget to connect the 4-pin ATX +12V power plug. Otherwise, the system will not boot up. • We recommend that you use a PSU with higher power output when configuring a system with more power-consuming devices or when you intend to install additional devices. The system may become unstable or may not boot up if the power is inadequate.
  • Page 24 PORT1 L AGND AGND MIC2 PIN 1 PIN 1 HD-audio-compliant Legacy AC’97 pin definition compliant definition B85M-VIEW PAKER Front panel audio connector • We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. • If you want to connect a high-definition front panel audio module to this connector, set the Front Panel Type item in the BIOS setup to [HD]. If you want to connect an AC’97 front panel audio module to this connector, set the item to [AC97]. By default, this connector is set to [HD]. See section 2.6.8 Onboard Devices Configuration for details. Speaker connector (4-pin SPEAKER) The 4-pin connector is for the chassis-mounted system warning speaker. The speaker...
  • Page 25 B85M-VIEW PAKER Fan connectors Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! The CPU_FAN connector supports a CPU fan of maximum 1A (12 W) fan power. Only 4-pin CPU fans and chassis fans support the ASUS FAN Xpert feature. Intel B85 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~2 [dark brown]) ® These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical drives via Serial ATA 3.0 Gb/s signal cables. B85M-VIEW PAKER B85M-VIEW PAKER SATA 3.0Gb/s connectors When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to [AHCI]. See section 2.6.3 SATA Configuration for details. ASUS B85M-VIEW PAKER 1-17...
  • Page 26 USB 3.0 connector (20-1 pin USB3_12) This connector allows you to connect a USB 3.0 module for additional USB 3.0 front or rear panel ports. With an installed USB 3.0 module, you can enjoy all the benefits of USB 3.0 including faster data transfer speeds of up to 5Gbps, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. USB3_12 PIN 1 USB3+5V USB3+5V IntA_P1_SSRX- B85M-VIEW PAKER IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ IntA_P1_SSTX- IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ IntA_P1_D- IntA_P2_D- IntA_P1_D+ IntA_P2_D+ B85M-VIEW PAKER USB3.0 Front panel connector The USB 3.0 module is purchased separately. 1-18 Chapter 1: Product introduction...
  • Page 27 This USB connector complies with USB 2.0 specifications and supports up to 480Mbps connection speed. B85M-VIEW PAKER USB1314 USB_P13+ USB_P14+ USB_P13- USB_P14- USB+5V USB+5V PIN 1 B85M-VIEW PAKER USB2.0 connector Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. DVI connector (18-pin DVI2) This 16-pin connector is for a DVI monitor or other DVI-compatible devices. DVI2 B85M-VIEW PAKER DVI_TXDN2 DVI_HPD DVI_TXDN2 DVI_TXDP1...

  • Page 28: Chassis Intrusion Connector

    By default, the pins labeled “Intruder” are shorted with a jumper cap. Remove the jumper caps only when you intend to use the chassis intrusion detection feature. CHASSIS B85M-VIEW PAKER PIN 1 B85M-VIEW PAKER Chassis intrusion connector Before using this function, ensure that you enable it from Monitor > Chassis Intrude Support in the BIOS Setup program. mSATA/mPCIe slot (MSATA_MPCIE) This slot allows you to install a full length mSATA or mini-PCIe card, providing you with expandability and connectivity solutions for an optimal system performance. B85M-VIEW PAKER MSATA_MPCIE B85M-VIEW PAKER mSATA/mPCIe combo slot You can install either an mSATA card or an mPCIe card into this slot one at a time.

  • Page 29: System Panel Connector

    System panel connector (10-1 pin F_PANEL) This connector supports several chassis-mounted functions. F_PANEL +PWR_LED- PWR_BTN B85M-VIEW PAKER PIN 1 +HDD_LED- RESET B85M-VIEW PAKER System panel connector • System power LED (2-pin +PWR_LED-) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin +HDD_LED-) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HDD LED lights up or flashes when data is read from or written to the HDD. • ATX power button/soft-off button (2-pin PWR_BTN) This connector is for the system power button.

  • Page 30: Software Support

    Windows 8.1 (32bit/64bit) Operating Systems (OS). Always install the latest OS version and ® corresponding updates to maximize the features of your hardware. Motherboard settings and hardware options vary. Refer to your OS documentation for detailed information. 1.8.2 Support DVD information The Support DVD that comes with the motherboard package contains the drivers, software applications, and utilities that you can install to avail all motherboard features. The contents of the Support DVD are subject to change at any time without notice. Visit the ASUS website at www.asus.com for updates. To run the Support DVD Place the Support DVD into the optical drive. If Autorun is enabled in your computer, the DVD automatically displays the Specials screen which lists the unique features of your ASUS motherboard. Click Drivers, Utilities, AHCI Driver, Manual, Contact and Specials tabs to display their respective menus. The following screen is for reference only. Click an icon to display Support DVD/motherboard information Click an item to install If Autorun is NOT enabled in your computer, browse the contents of the Support DVD to locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run...

  • Page 31: Bios Information

    Managing and updating your BIOS Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility.

  • Page 32: Asus Ez Flash

    2.1.2 ASUS EZ Flash 2 The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS‑based utility. Before you start using this utility, download the latest BIOS file from the ASUS website at www.asus.com. To update the BIOS using EZ Flash 2: Insert the USB flash disk that contains the latest BIOS file to the USB port.

  • Page 33: Asus Crashfree Bios 3 Utility

    2.1.3 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains the updated BIOS file.
  • Page 34 ENTER to select boot device ESC to boot using defaults P2: ST3808110AS (76319MB) aigo miniking (250MB) UEFI: (FAT) ASUS DRW-2014L1T(4458MB) P1: ASUS DRW-2014L1T(4458MB) UEFI: (FAT) aigo miniking (250MB) Enter Setup When the booting message appears, press <Enter> within five (5) seconds to enter FreeDOS prompt.
  • Page 35 DO NOT shut down or reset the system while updating the BIOS to prevent system boot failaure. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit BIOS menu. See section 2.10 Exit Menu for details. ASUS B85M-VIEW PAKER...

  • Page 36: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. •...
  • Page 37 • The boot device options vary depending on the devices you installed to the system. • The Boot Menu (F8) button is available only when the boot device is installed to the system. ASUS B85M-VIEW PAKER...

  • Page 38: Advanced Mode

    BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To access the EZ Mode, click Exit, then select ASUS EZ Mode or press F7. Back button Menu items...

  • Page 39: Menu Items

    <Enter> to display a list of options. Quick Note button This button allows you to enter notes of the activities that you have done in BIOS. Last Modified button This button shows the items that you last modified and saved in BIOS Setup. ASUS B85M-VIEW PAKER...

  • Page 40: My Favorites

    My Favorites MyFavorites is your personal space where you can easily save and access your favorite BIOS items. Adding items to My Favorites To add frequently‑used BIOS items to My Favorites: Use the arrow keys to select an item that you want to add. When using a mouse, hover the pointer to the item.

  • Page 41: Main Menu

    RAM to clear the BIOS password. See section 1.6 Headers for information on how to erase the RTC RAM. • The Administrator or User Password items on top of the screen show the default Not Installed. After you set a password, these items show Installed. ASUS B85M-VIEW PAKER 2-11...

  • Page 42: User Password

    2.4.1 System Language [English] Allows you to choose the BIOS language version from the options. Configuration options: [English] [Español] [Русский] [한국어] 2.4.2 System Date [Day xx/xx/xxxx] Allows you to set the system date. 2.4.3 System Time [xx:xx:xx] Allows you to set the system time. 2.4.4 Security The Security menu items allow you to change the system security settings.

  • Page 43: Ai Tweaker Menu

    Scroll down to display the other items. Target CPU Turbo-Mode Speed : xxxxMHz Displays the target CPU Turbo‑Mode speed. Target DRAM Speed : xxxxMHz Displays the target DRAM speed. Target Cache Speed : xxxxMHz Displays the target Cache speed. ASUS B85M-VIEW PAKER 2‑13...

  • Page 44: Dram Timing Control

    Target DMI/PEG Clock : xxxxMHz Displays the target DMI/PEG clock. Target CPU Graphics Speed : xxxxMHz Displays the target CPU Graphics speed. 2.5.1 DRAM Frequency [Auto] Allows you to set the memory operating frequency. The configurable options vary with the BCLK (base clock) frequency setting.
  • Page 45 Allows you to configure the total power range, and extends the overclocking frequency range simultaneously. Configuration options: [Auto] [100%] [110%] [120%] [130%] [140%] Choose a higher value when overclocking, or under a high CPU loading for extra power support. ASUS B85M-VIEW PAKER 2-15...

  • Page 46: Cpu Power Management

    2.5.6 CPU Power Management The subitems in this menu allow you to set the CPU ratio and features. Enhanced Intel SpeedStep Technology [Enabled] ® Allows you to enable or disable the Enhanced Intel SpeedStep Technology (EIST). ® [Disabled] Disables this function. [Enabled] The operating system dynamically adjusts the processor voltage and core frequency which may result in decreased average consumption and...
  • Page 47 Allows you to set the power saving level 3 threshhold. Use the <+> and <‑> keys to adjust the value. 2.5.7 CPU Spread Spectrum [Auto] [Auto] Automatic configuration. [Disabled] Enhances the BCLK overclocking ability. [Enabled] Sets to [Enabled] for EMI control. ASUS B85M-VIEW PAKER 2-17...

  • Page 48: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 2.6.1 CPU Configuration The items in this menu show the CPU‑related information that the BIOS automatically detects.
  • Page 49 Allows you to set the processor cores to run faster than the marked frequency in a specific condition. Configuration options: [Enabled] [Disabled] Turbo Mode is only available on selected CPU models only. CPU C states [Auto] [Auto] Automatic configuration. [Enabled] Enables the CPU C states. [Disabled] Disables the CPU C states. ASUS B85M-VIEW PAKER 2-19...

  • Page 50: Pch Configuration

    The following items appear only when you set the CPU C states to [Enabled]. Enhanced C1 state [Enabled] [Enabled] Enables enhanced C1 state. [Disabled] Disables enhanced C1 state. CPU C3 Report [Enabled] Allows you to disable or enable the CPU C3 report to OS. Configuration options: [Enabled] [Disabled] CPU C6 report [Enabled] Allows you to disable or enable the CPU C6 report to OS.

  • Page 51: Sata Configuration

    Set to [AHCI] when you want the SATA hard disk drives to use the AHCI (Advanced Host Controller Interface). The AHCI allows the onboard storage driver to enable advanced Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands. ASUS B85M-VIEW PAKER 2-21...

  • Page 52: System Agent Configuration

    Aggressive LPM Support [Auto] This item appears only when you set the previous item to [AHCI] and allows you to enable or disable PCH entering link power state aggressively. Configuration options: [Auto] [Disabled] [Enabled] IDE Legacy / Native Mode Selection [Native] This item appears only when you set the SATA Mode Selection item to [IDE].

  • Page 53: Dmi Configuration

    H/W is always enabled. This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the SPI device. ® • The following two items become configurable only when you set the Intel AMT item to [Enabled]. ASUS B85M-VIEW PAKER 2‑23...

  • Page 54: Usb Configuration

    BIOS Hotkey Pressed [Disabled] This item become configurable only when the previous item is set to [Enabled] and allows you to enable or disable this function. Configuration options: [Enabled] [Disabled] Un-Configure ME [Disabled] Sets this item to [Disabled] to unconfigure AMT/ME without using a password or set it to [Enabled] to use a password.

  • Page 55: Onboard Devices Configuration

    When enabled, the system in S4 state will further reduce power usage and will power off the USB and PS/2 devices. The system in deep S4 state can be woken up via the power button, devices in LAN, or other ways except via the USB and PS/2 devices. Configuration options: [Disabled] [Enabled] ASUS B85M-VIEW PAKER 2-25...

  • Page 56: Network Stack Configuration

    Restore AC Power Loss [Power Off] [Power On] The system goes into on state after an AC power loss. [Power Off] The system goes into off state after an AC power loss. [Last State] The system goes into either off or on state, whatever the system state was before the AC power loss.

  • Page 57: Monitor Menu

    CPU Fan Speed Low Limit [200 RPM] This item appears only when you enable the CPU Q‑Fan Control feature and allows you to disable or set the CPU fan warning speed. Configuration options: [Ignore] [100RPM] [200RPM] [300 RPM] [400 RPM] [500 RPM] ASUS B85M-VIEW PAKER 2-27...
  • Page 58 CPU Fan Profile [Standard] This item appears only when you enable the CPU Q‑Fan Control feature and allows you to set the appropriate performance level of the CPU fan. [Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on the CPU temperature.
  • Page 59 The signal is then generated as a chassis intrusion event. Configuration options: [Disabled] [Enabled] 2.7.7 Anti Surge Support [Disabled] This item allows you to enable or disable the Anti Surge function. Configuration options: [Disabled] [Enabled] ASUS B85M-VIEW PAKER 2-29...

  • Page 60: Boot Menu

    Boot menu The Boot menu items allow you to change the system boot options. Scroll down to display the other items. 2.8.1 Fast Boot [Enabled] [Enabled] Select to accelerate the boot speed. [Disabled] Select to go back to normal boot. The following five items appear when you set Fast Boot to [Enabled].
  • Page 61 [Disabled] Hide the logo during POST. Set this item to [Full Screen] to use the ASUS MyLogo 2™ feature. POST Delay Time [3 sec] This item appears only when you set Boot Logo Display to [Auto] and [Full Screen]. This item allows you to select the desired additional POST waiting time to easily enter the BIOS setup.
  • Page 62 2.8.4 Wait for ‘F1’ If Error [Enabled] When this item is set to [Enabled], the system waits for the F1 key to be pressed when error occurs. Configuration options: [Disabled] [Enabled] 2.8.5 Option ROM Messages [Force BIOS] [Force BIOS] The third‑party ROM messages will be forced to display during the boot sequence.

  • Page 63: Secure Boot

    Secure Boot keys will not be active. Configuration options: [Yes] [No] Load PK from File Allows you to load the downloaded PK from a USB storage device. The PK file must be formatted as a UEFI variable structure with time‑based authenticated variable. ASUS B85M-VIEW PAKER 2‑33...
  • Page 64 KEK Management The KEK (Key‑exchange Key or Key Enrollment Key) manages the Signature database (db) and Revoked Signature database (dbx). Key‑exchange Key (KEK) refers to Microsoft Secure Boot Key‑Enrollment Key (KEK). ® Delete the KEK Allows you to delete the KEK from your system. Configuration options: [Yes] [No] Load KEK from File Allows you to load the downloaded KEK from a USB storage device.

  • Page 65: Tool Menu

    <Enter> to display the submenu. 2.9.1 ASUS EZ Flash 2 Utility Allows you to run ASUS EZ Flash 2. Press [Enter] to launch the ASUS EZ Flash 2 screen. For more details, see section 2.1.2 ASUS EZ Flash 2. 2.9.2 ASUS Overclocking Profile This item allows you to store or load multiple BIOS settings.

  • Page 66: Exit Menu

    This item allows you to load or save profile from your USB drive, load and save profile to your USB drive. 2.9.3 ASUS SPD Information DIMM Slot Number [DIMM_A1] Displays the Serial Presence Detect (SPD) information of the DIMM module installed on the selected slot.
  • Page 67 This option allows you to enter the EZ Mode screen. Launch EFI Shell from filesystem device This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available devices that have a filesystem. ASUS B85M-VIEW PAKER 2‑37...
  • Page 68 2‑38 Chapter 2: Getting started...

  • Page 69: Appendices

    Cet appareil est conforme aux normes CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d’interférences et (2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil. ASUS B85M-VIEW PAKER...

  • Page 70: Canadian Department Of Communications Statement

    ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.

  • Page 71: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 General support +1-812-282-2787 Online support http://www.service.asus.com/ ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555...
