IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE APPLIANCE INSTRUCTIONS
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
300109-16
TC36.NGST03.C
TC36 See-Thru
BLACK DIAMOND
BURNER KIT
TC36.NGST03.C
PART#
FOR TC36
SEE-THRU
SERIES C
5056.42801.C3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36.NGST03.C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for T&C TC36.NGST03.C

Summary of Contents for T&C TC36.NGST03.C

  • Page 1 Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC36 See-Thru BLACK DIAMOND BURNER KIT TC36.NGST03.C PART# FOR TC36 SEE-THRU SERIES C 300109-16 TC36.NGST03.C...

  • Page 2: Package Contents

    2 MEDIA SPACER, FRONT/REAR ..........................9695 1 MEDIA SPACER, CENTER ............................9694 1 TUMBLED GLASS MEDIA ............................. 5012.01 1 HARDWARE PACKAGE ..........................TC36.STHK03 1 PILOT ASSEMBLY..............................5005.025 1 1/4” FLEX COMPRESSION ..........................5019.225 1 1/2” FLEX FLARE CONNECTION ........................5019.223 Fig. # 1 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 3 Seal the remaining holes in the floor of the fireplace with screws. (Fig. #4). Connect the manifold flex gas line and pilot flex gas line to the bulkhead ensuring a gas-tight connection. 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 4 Install the right porcelain panel (as in Fig. #3). Fig. # 7 Position the right burner shield over the inlet cover ensuring that the pilot assembly is protruding through the half-hole between the inlet cover and the right burner shield (Fig. #7). 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 5 10. Install the front burner shield positioning the support tab under the right burner shield (Fig. #9). Fig. # 10 11. Install the left burner shield. This will be a snug fit requiring some alignment (Fig. #10). 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 6 (control side). Fig. # 13 13. Attach the pilot assembly to burner tray using two screws (Fig. #13). Fig. # 14 14. Position a front/rear media spacer at the rear of the burner tray (Fig. #14). 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 7 NOTE: Shutter must be fully open for propane or fully closed for natural gas (push down on the shutter control rod to open, pull up to close). Some adjustment may be required (see page 13). 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 8 (Fig. #19) and spread the glass evenly over top of the tube and media spacers (Fig. #20). NOTE: Too much tumbled glass over the burner will cause sooting. Fig. # 20 300109-16 TC36.NGST03.C 5056.42801.C3...

  • Page 9: Propane Conversion

    Using a 7/16” wrench loosen the pilot head on the pilot assembly. Slide the pilot adjustment plate over and ensure that the hole in the plate is showing (Fig. #23 indicates NG position, Fig. #24 indicates LP position). 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 10 Fig. # 26 Minimum 15) Replace the minimum rate screw rate screw with the one provided in the propane conversion kit supplied with this fireplace. Ensure that the screw is fully installed. (Fig. #26) 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 11 18) Fill in the date and the name of the person who performed the conversion in the white area on the conversion label. Peel off the protective backing and apply the conversion label directly over the gas specifications on the rating label. 300109-16 TC36.NGST03.C 5056.42801.C3...

  • Page 12: Gas Pressure Check

    (Fig. #31) 3) Attach a pressure gauge onto the fitting. 4) When testing is complete shut of the gas, remove the fitting and replace the plug. Thread sealant will be required to ensure a gas tight connection. 300109-16 TC36.NGST03.C 5056.42801.C3...

  • Page 13: Burner Flame Adjustment

    NOTE: Proper air shutter setting is required. The flame should be just orange and “lazy”. It should NEVER be set to create sooting on internal parts and window glass. Fig. # 33 300109-16 TC36.NGST03.C 5056.42801.C3...

  • Page 14: Replacement Parts

    #25 ORIFICE, NG 5021.31 3/32 ORIFICE, LP 5002.9692 SHUTTER CONTROL ROD 5019.225 1/4” FLEX COMPRESSION 5019.223 1/2” FLEX FLARE CONNECTION 9693.2 BURNER SHIELD, LEFT 9697 AIR CHANNEL INSERT 9690 BURNER TRAY TC36.STHK03 HARDWARE PACKAGE 5012.01 TUMBLED GLASS, 5lbs 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 15 Notes 300109-16 TC36.NGST03.C 5056.42801.C3...
  • Page 16 TOWN & COUNTRY FIREPLACES Technical Support: 1-877-715-2664 www.townandcountryfireplaces.net 2975 Allenby Rod, Duncan, BC Canada V9L 6V8...
